cnReach N500 User Guide System Configuration

phn-4980_001v004 August 2019)

2-90

depending on the speed of the air interface or if you user is connected directly to the Ethernet port on

the radio.

Software for the radio can downloaded from Cambium Networks support website:

https://support.cambiumnetworks.com/files/n500/

Attention

Note that there are different radio firmware files depending on the band of the radio. The

band is denoted in the filename (eg. 450 = 403-470MHz radios; 900 = 902-960 MHz

radios.

Attention

Avoid interrupting power to the radio after clicking apply to prevent corruption of the

radio’s internal memory.

Task 1: Update OS software

The OS file consists of the cnReach application software and underlying operating system. To upgrade

to a new version of firmware, first select upload. You will be presented with a standard file selection

dialog box. Select the desired version. After the file is uploaded, the name of the file will appear in the

box as shown in screenshot below.

Select Apply to install the new version replacing the previous version. You can also select delete if

you’d like to remove this image from the device.

Task 2: Update Radio software

This process is similar to the OS update described above. Note that in dual-radio modules, there will be

two Radio options. The apply button must be selected twice to apply the new image to each radio in

turn (Rad1 and Rad2)

Task 3: Update Configuration file

The Configuration section of this page allows the user to collect the current configuration of the module

(Download), send a new configuration to the module (Upload) or apply a configuration (Apply). Note

that if the current configuration file is deleted or doesn’t appear in the Configuration window, the

current configuration file will be re-generated and re-populated the next time a configuration change is

made and committed to the radio.

Note: the transfer log 1 and transfer log 2 links are not currently used.
