WISP Features 288

WISP Features

This chapter presents new functionality available only on the WISP switches, i.e. the TX2020R-P,

TX2012R-P, and the TX2028RF-P.

Power over Ethernet

Note

l

For TX2020R-P, ports 1-8 are 4-Pair PoE ports, and ports 9-16 are 2-Pair PoE

ports.

l

For TX2012R-P, ports 1-4 are 4-Pair PoE ports, and ports 5-8 are 2-Pair PoE

ports.

l

For TX2028RF-P, ports 1-8 are 4-Pair PoE ports, and ports 9-16 are 2-Pair

PoE ports.

l

4-Pair ports support up to 90w (802.3bt Type4/Class8).

l

2-Pair ports support up to 30w (802.3bt Type3/Class4).

l

For TX2020R-P the maximum PoE budget is 960W.

l

For TX2012R-P the maximum PoE budget is 480W.

l

For TX2028-RF-P the maximum PoE budget is 960W.

PoE configurable power modes

Passive 24V mode

Passive 24V mode is a Cambium-specific implementation of passive PoE to function at 24V, as oppose to

standard 802.3 PoE which delivers power at 54V. In this mode, no detection or classification is

performed. 24V is forced on the port.

Note that the voltage output range from cnMatrix is 22V to 26V.

For this mode, the PoE LED will light up green. For standard 802.3bt mode, the PoE LED will light up

amber.

Note

Passive 24V mode is only available on ports 9-16 of TX2020R-P or TX2028RF-P

and ports 5-8 of TX2012R-P.

Caution

Passive 24V mode may cause damage to devices since it automatically puts

power on the line. Check that a device is compatible with this passive power

mode before using it.
