L2 Features 145

l

LLDP-SYS-NAME – match LLDP System Name TLV data.

l

LLDP-SYS-DESC – match LLDP System Description TLV data.

l

LLDP-CHASSIS – match LLDP Chassis ID TLV data.

l

LLDP-PORT – match LLDP Port ID TLV data.

l

LLDP-PORT-DESC – match LLDP Port Description TLV data.

l

MAC-OUI – match learned MAC address OUIs against device ID data.

l

MAC-FULL – match learned MAC addresses against device ID data.

l

MAC-RANGE – compare learned MAC addresses against MAC address range device ID data.

l

MAC-LIST – compare learned MAC addresses against a non-contiguous MAC address range

(MAC list file).

l

LLDP-IPV4-MGMT – match LLDP Management Address TLV IPv4 IP address data.

l

default - match any MAC address.

4. PBA rule usage restrictions:

l

Rule name is limited to 1 to 32 characters and must be unique.

l

Device identification string is limited to 1 to 60 characters.

l

Rules that are referenced by a policy cannot be deleted. Rules can be modified, even when

referenced. Modification of a referenced rule causes the associated policy to be reapplied

(if it is still applicable).

l

A maximum of 50 rules can be defined.

l

MAC address device identification format is xx:xx:xx (OUI), xx:xx:xx:xx:xx:xx (FULL) or

xx:xx:xx:xx:xx:xx,yy:yy:yy:yy:yy:yy (RANGE).

l

The low MAC address range value must be less that the high MAC address value (low and

high).

l

Only one rule with rule type ‘default’ can be defined.

l

The device identification string for rule type default is ignored, if specified (optional for rule

type default).

l

A rule combination name is limited to 1 to 32 printable ASCII characters.

l

A MAC list file must be downloaded before a rule referencing the MAC list can be created

with the MAC-LIST rule type.

5. Type the pba action (or auto-attach action) "AP_VLANs" vlan 100,101 pvid 100 command into the

terminal to configure PBA/Auto-Attach action information. Press the Enterkey.

AP_VLANs = unique action name.

vlan 100, 101 = list of VLANs to be created.

pvid 100= pvid value; this has to bea value specified in the VLAN list.

6. PBA action usage restrictions:

l

Action name is limited to 1 to 32 characters and must be unique.

l

A VLAN list (vlan option) is comprised of 1 to 20 comma-separated VLANs.

l

Specifying a native VLAN (pvid option) update requires a VLAN list containing the PVID

VLAN be specified.
