7
SD675650 ISSUE 6 M172 DELTA
Delta operating on maximum dehumidification of pool air wi full heat recovery to pool water
and air. Available energy is removed from exhaust air stream. Supplementary heat, if required,
supplied by LPHW (water or air).
CONDENSATE
Return Air
Supply Air
Full Dehumidification&Heat Recovery
WARM DRY AIR
HOT DRY AIR
COOL DRY AIR
WARM HUMID AIR
Full dehumidification and heat recovery
Delta operating on light dehumidification wi full heat recovery and reduced fresh air stream –
control system automatically selects correct operating mode and damper position. LPHW heat
available when required.
CONDENSATE
Return Air
Supply Air
Light Dehumidification&Heat Recovery
WARM DRY AIR
HOT DRY AIR
COOL DRY AIR
WARM HUMID AIR
Light dehumidification and heat recovery
Delta models 4 and above provide an air conditioning facility to minimise e effects of solar gain
from larger glazed areas or very high usage. Automatic damper and mode control.
Return Air
Supply Air
CONDENSATE
Air Conditioning
WARM DRY AIR
HOT DRY AIR
COOL DRY AIR
WARM HUMID AIR
Air conditioning
Air temperature set back control is incorporated as standard in all Delta units and controlled by a
time clock. Pool hall air is dropped to a lower temperature for maximum economy. Air recircula-
tion is maintained, dampers allow low fresh air flow.
CONDENSATE
Return Air
Supply Air
Night Set Back
WARM DRY AIR
HOT DRY AIR
COOL DRY AIR
WARM HUMID AIR
Night set back
1.1 HOW THE AIR FLOWS THROUGH THE DELTA
