54
SD675650 ISSUE 6 M172 DELTA
DELTA SYSTEM OWNER INSTALLATION MANUAL
1 2 3 4 5
AIR STAT
HUMIDITY STAT
Remote sensor box
All Deltas
Remove covers
Disconnect probe/sensor wires from terminals 60-64 here
(Middle of control box)
62
63
64
61
60
Connect terminals in sensor box to
control box terminal numbers
Replace covers
3.12 OPTIONAL REMOTE SENSOR BOX
A remote sensor box is available allowing e air temperature and humidity
sensors to be mounted in e pool hall. This may be beneficial if e sensors
located wiin e Delta cabinet are not able to get a representative
measurement of e conditions.
When using 0.5mm² cable, e maximum total distance between e sensors
and eir terminals is 20 metres.
Aer e Remote Sensor Box has been connected it may be necessary to
calibrate e sensor offsets. See Advanced Settings, OFFSETS for how to do is.
