Exploded View/Parts List
REF. NO. GE PART NO. PART DESCRIPTION (01)
0111 WS19X10005 SUPPORT SCREEN 1
0112 WS03X10013 SCREEN 1
0113 WS22X10036 FLOW PLUG, .15 GPM 1
0114 WS08X10008 GASKET, NOZZLE/VENTURI 1
0115 WS03X10073 CONE SCREEN 1
0116 WS22X10021 PLUG, FILL FLOW .30 GPM 1
0117 WS03X10017 NUT FERRULE 1
0118 WS15X10034 NOZZLE/VENTURI BODY 1
0119 WS03X10018 RETAINER 1
:6; 6($/25,1*Ǝ;Ǝ
0121 WS15X10025 BODY, VALVE 1
0122 WS03X10020 SPRING 1
0123 WS22X10029 PLUG, DRAIN SEAL 1
0124 WS15X10046 NOZZLE/VENTURI ASM. 1
0125 WS03X10043 WAVE SPRING BEARING 1
0130 WS35X10020 SEAL KIT 1
0132 WS22X10065 DRAIN HOSE ADAPTER KIT 1
0136/0140 WS26X21821 MOTOR, CAM & GEAR KIT, 1" 1
0137 WS26X10009 BEARING 1
0138 WS26X10023 PLATE, MOTOR 1
:6; 6&5(:;Ǝ
:6; 6&5(:;Ǝ
:6; $'$37(5±1377+5($'±Ǝ9$/9(
0145 WS60X10008 CLIP 4
0146 WS28X10018 HARNESS WIRE, SENSOR ASSY 1
0148 WS26X10030 TURBINE & SUPPORT ASSEMBLY* 1
0151 WS15X10078 BYPASS ASM. 1
0152 WS03X10072 SEAL, O-RING 4
0153 WS15X21985 WATER SHUTOFF VALVE 1
0998 WS35X10065 INSTALLATION KIT 1
* Includes 2 each of REF. NO. 145 (CLIP) & REF. NO. 152 (O-RING)
