Exploded View/Parts List
REF. NO. GEA PART NO. PART DESCRIPTION (01)
0002 WS31X10051 BACK COVER, ELECTRONICS 1
0003 WS35X10001 O-RING SEAL KIT 1
0004 WS35X21986 DECAL, FACEPLATE 1
0005 WS07X10004 HOSE, DRAIN, 20 FT. 1
0006 WS31X10044 FILTER SCREEN 1
0007 WS14X10002 DISTRIBUTOR, TOP 1
0008 WS14X10005 DISTRIBUTOR, BOTTOM 1
0009 WS01X10002 RESIN, 1-CU. FT. 1
0010 WS32X10011 TANK, RESIN 9 X 40
0011 WS31X10052 COVER, TOP 1
0012 WS34X10021 FACEPLATE 1
0013 WS35X21984 MAIN CONTROL BOARD KIT 1
0016 WS26X22083 EXTERNAL POWER SUPPLY WITH POWER CORD 1
0017 WS31X10053 COVER, SALT HOLE, WITH LABELS 1
0019 WS33X21987 RIM 1
0020 WS33X10024 COVER, BRINEWELL 1
0022
WS34X10025 BRINEWELL 1
0023 WS02X10088 SCREW KIT, BRINE TANK 1
0024 WS32X10032 TANK, BRINE 1
0026 WS22X10063 OVERFLOW ADAPTER KIT 1
0029 WS15X24201 BRINE VALVE ASM. 1
0040 WS35X21981 WIFI MODULE KIT 1
0041 WS01X21982 HOLDER, WIFI MODULE 1
0042 WS21X21983 CABLE ASM., WIFI MODULE 1
0056 WS28X10078 TANK NECK CLAMP KIT 1
0101 WS02X10023 SCREW. # 4 - 24 X 3/4” 2
0103 WS21X10003 SWITCH 1
0105 WS02X10024 SCREW. # 10 - 2 5/8” 8
0106 WS31X10013 COVER, VALVE 1
0107 WS03X10034 WASHER WAVE 1
0108 WS26X10010 ROTOR & DISC ASM. 1
0109 WS19X10010 CAP 1
0110 WS03X10011 SEAL, O-RING 1.125 X 1.37 1
