10
Fig. E
Fig. F
6) With Phillips head screwdriver,
unscrew and remove both light cover
brackets. Figs. E-F-G.
Fig. G
Fi
g
. H
7) Slide the LED light assembly out of
the light cover. Figs. H-I.
Fig. I
Fig. J`
OLD LED light
Fig. K
8) Carefully unsnap the LED light
assembly from the wire clip, and replace
it with the new LED light assembly.
Figs. J-K-L.
Fig. L
NEW LED light
Fig. M
9) Replace the top cover bracket, but
do not fully tighten the screws yet.
Fig. N
10) Slide the LED light assembly fully
into the light cover. Figs. N-O.
Fig. O
Fig. P 11) Slide the light cover into
the top bracket, making sure the
white side of the cover is facing up.
Fig. Q
12) With the wire notch facing down,
replace the bottom bracket.
Fig. R 13) Attach the bottom cover
bracket, making sure the wire is seated
in the wire notch.
