4
9
The optional factory-installed swing-open doors for
CBC-GG-B2 series carts have a twist lock. (Fig. E)
The optional factory-installed sliding doors for
CBC-GG-B3 & CBC-GG-B4 series carts have a push-in
lock. Pushing in the lock will set the lock. (Fig. F)
Use keys provided to open the lock on all models.
***NOTE: 2 keys are supplied with each cart.
Cadco cannot provide replacement keys because each
lock is keyed differently. We strongly recommend that
you have duplicate keys made at a hardware store or
other key vendor as soon as you receive your cart.
OPTIONAL SECURITY DOORS: KEYS/ LOCKS (Figs. E-F)
Fig. E
Fig. F
The optional PW-4 Pneumatic Wheels Kit may be ordered
2 different ways:
1) At time of cart purchase (on the same PO), in which case
they will be factory-installed on the cart. (The smaller standard
casters will be included in a package inside the shipped
cart, in case end-user later wants to use them on cart.)
2) As a separate purchase, after cart has been ordered on
a separate PO. In this case the end-user may install the
PW-4 wheels by removing the smaller casters that were
factory-installed and attaching the PW-4 wheels using the
same hardware and holes.
OPTIONAL PNEUMATIC WHEELS: (Fig G)
DISASSEMBLY FOR SERVICING OPTIONAL BUFFET SERVER TOP
(Models with optional Heat Package only)
These carts were designed to allow easy removal of the carts buffet server top
to facilitate servicing the electrical components, if required.
Tool required: 5/32 Allen key (also known as Allen wrench,
Allen hex wrench, L-hex key, Hex key, etc.) (not included)
1. Remove buffet server pans/lids and pan holders (see pg. 6 & Fig. I.)
2. Remove merchandising shelves assembly by unscrewing the 2 thumbscrews
on either side of the cart, and lifting the shelves assembly off the cart. (Fig.
M.)
3. Remove the screws at the bottom corners of the safety shields (8 screws total;
2 per corner) (Fig. M.)
3. Lift the top of the cart off the base, (Fig. N) and turn top over to access the
electrical components. (Be sure to have a Cadco authorized service center
handle the repair work, to avoid voiding the warranty.)
4. After repairs are completed, reverse above directions to re-assemble.
Fig. M
Allen key
Thumbscrews
Fig. N
Buffet server cart top
(generic cart photo)
Safety shield
Fig. G
