BEFORE YOU BEGIN
Be sure to remove the protective film from all surfaces before using the cart. (FIG. A.)
FLIP-UP SHELF
Your Grab & Go Cart is equipped with a flip-up shelf. (Fig. B.) To raise the shelf,
lift it until you hear the clicks which indicate it locking (on both sides) in upright
position.
To lower the shelf, squeeze the shelf lock tabs up on each side, and lower the
shelf. Maximum weight load for the shelf is 35-40 lbs.
Shelf lock tab
Fig. A
Fig. B
ASSEMBLY - BASE MODELS
1. Before assembling, wash removable parts in warm
sudsy water, rinse and dry. Clean the cart with a mild
detergent and a soft moist cloth. Do not use any
scouring agents!
2. Place each pan holder (Fig. C1) over the carts
top warming surface, with 2 keyhole slots and 2 open
slots on the inside flaps of the pan holder positioned over the 4 locking knobs
on the warming surface (Figs. C2-3). Press pan holder down onto warming
surface, and slide pan holder until knobs engage (Fig. C4). Tighten knobs to keep
pan holder in place. (Reverse steps to remover pan holder for cleaning, or to switch
to optional Cold Bay Panholder Kit.)
Pan Holder
Keyhole slots
Open slots
Pan Holder
Locking Knobs on
Cart Warming Surface
Cart Surface
1 2
Cart Surface
3
Pan Holder
Locking Knobs
Locking Knobs
Cart Surface
4
Pan Holder
Locking Knobs
Locking Knobs
OPTIONAL ADJUSTABLE HEIGHT
INNER SHELF/ SHELVES (Fig. D.)
(for model #s to order, see page 10)
To install shelf or adjust shelf height, tilt shelf
up slightly and position/ reposition by resting
shelf on your choice of shelf support knobs
on both sides of the cart interior (CBC-GG-B2
models) or on cart side and center column
(CBC-GG-B3/B4 models.) Be sure the shelf is
resting securely on the 4 shelf support knobs
before placing anything on the shelf.
Shelf
support
knobs
Fig. D
Fig. C
OPTIONAL ACCESSORIES INSTALLABLE BY USER
PS-CBC-6 - Pan Holder Accessory for 6 Deep Cambro ColdFest Pans
l Stainless pan holder accommodates 2 half size, 6 deep
Cambro
®
ColdFest
TM
pans (or equivalent); pans not included
l Converts cart hot bay to cold bay without tools.
l May be attached/ detached by end user.
PS-CBC-6CP - Cold Bay Pan Holder Kit
l Stainless pan holder with 2 half size, 6 deep Cambro
®
ColdFest
TM
pans with Cambro
®
lids.
l Converts cart hot bay to cold bay.
l May be attached/ detached by end user.
PS-CBC-4 - Pan Holder Accessory for 4 Deep Steam Pans
l Stainless pan holder accommodates 2 half size, 3 third size,
or 1 full size 4 deep steam pan on cart surface
PS-CBC-2 - Pan Holder Accessory for 2-1/2 Deep Steam Pans
l Stainless pan holder accommodates 2 half size, 3 third size,
or 1 full size 2-1/2 deep steam pan on cart surface
GGAS-2 - Adjustable Inner Shelf for CBC-GG-B2
l One stainless shelf; spans whole cart interior
GGAS-3 - Adjustable Inner Shelves for CBC-GG-B3
l Set of 2 stainless shelves; each spans half of cart interior
GGAS-4 - Adjustable Inner Shelves for CBC-GG-B4
l Set of 2 stainless shelves; each spans half of cart interior
PW-4 - Outdoor Pneumatic Wheels Kit
l Set of (4) 8 diameter pneumatic wheels with locks
l Rubber wheels with steel hardware
l 10 total floor/ ground clearance
