- Operating water temperature: 5˚C ( 41˚F ) – 35˚C ( 95˚F ).
- For the purposes of recharging the battery, only use the detachable supply unit ( external adaptor
model number: DSS12D-0841000-B / DSS12D-0841000-C / DSS12D-0841000-D / LX084100U )
- Connect the external adaptor to a power source through a residential current device ( RCD ) / a
ground fault circuit interrupter ( GFCI ). If in doubt, consult a qualified electrician.
- Disconnect the robot from the supply mains and make sure the robot is OFF prior to carrying out
regular maintenance – such as cleaning the filter, swivel smoothing-ring, and the areas around the
- Do not attempt to replace the installed rechargeable Li - ion battery pack.
- You should not operate this robot when people and/or pets are present in the water.
- For details regarding battery recycling/disposal, refer to the section “
DO NOT use this robot right after pool-shocking. It is recommended to first leave the pool circulating for at least 24 - 48 hours.
- DO NOT use this robot with another automatic cleaner/cleaner simultaneously in the pool.
adaptor /charging cable or pull the cord to disconnect it from the power source and charging cable.
Pool / spa owners should always exercise extra caution and common sense when utilizing the product.
HOW THE ROBOT WORKS
The robot has a water-propelling nozzle at the bottom of the swivel head. Water is first sucked in through the suction mouth
at the bottom of the robot, which then goes through the filter and is discharged via the propelling nozzle. Water jetting from the
nozzle propels the robot forward. Once the robot stops against an obstacle such as the pool wall, its side flap sways and its
swivel head turns 180˚, allowing the robot to move in the opposite direction. The robot moves in a generally straight pattern in
one direction and in an arc pattern in the other direction. The robot vacuums the pool bottom as it moves, collecting debris in
its compartment.
GETTING STARTED
Charging The Battery
IMPORTANT NOTE: Fully charge the robot ( about 6 hrs ) before using it for the first time.
WARNING!
• Use only the original external adaptor and charging cable provided.
• Make sure the robot and the charging port are clean and dry before set-up and charging.
( TIPS: Pry open the protective cover and use a cotton bud to dry the charging port and charging pins )
• The charging pins are waterproof. However, remnants of water in the port and around the pins could
result in natural occurrence of stains ( a byproduct of chemical reaction between water and electric
currents ). Otherwise, the stains can be removed by light scrubbing with a cotton bud soaked with
juice of lemon or vinegar.
• Make sure the robot is off by sliding the switch to the OFF position prior to charging.
1. Place the unit on a flat surface. Slide the switch to the OFF position.
2. Plug the charging cable of the external adaptor into the charging cable. Pry open the protective
cap. Align and insert the plug of the charging cable into the charging port at the top of the unit.
WARNING! Be sure not to invert the charging cable and ensure both the charging cable and
charging port are clean and dry before charging them. TIPS: Use cotton bud to dry the charging
port and pins.
3. Connect the external adaptor to the power source. The indicator light on the external adaptor turns
red once the charging begins. The indicator light on the external adaptor will turn green when the
robot is charged.
4. When charging is complete, disconnect the external adaptor from the power source and unplug the
Normally the robot can operate up to 45 minutes on a full charge.
Once the lifespan of the battery reaches its end, refer to section “
Let the robot rest for around 30 to 40 minutes before charging it again.
1. Bring the robot to the side of your pool.
First, align and attach the retrieval cord to the side notches at the top as you wrap the cord around the stem (
3. Slide the power switch to “ ” ( while the robot is still submerged ) – the indicator light will turn on and activate the motor
automatically ( water level covering the sensors at the top of the swivel head ). Let the robot sink to the pool floor and observe
retrieve it and redeploy it while making sure its front/back is facing the pool wall
No light - Power off / no power
Light - Power on
Blinking light - Battery power will be exhausted within 5 - 10 minutes.
4. To retrieve the robot from the pool, attach the hook to a telescopic pole ( not provided ) and use it to retrieve the float, if you
( for Australia / New
5. Slide the power switch OFF. Rinse the robot with fresh water after every use. DO NOT use any detergent.
6. Dry the charging port and pins thoroughly (
Before cleaning the debris compartment, make sure the robot is
clips are secured to the base. A “click” sound will
Before redeploying the robot to the pool, hold onto the wings on the body top cover to sway the robot slightly, to ensure
Float Replacement
Use a screwdriver ( not provided ) to unscrew the 4 screws at on the top cover of the swivel head. Untie the knot on the string
Flap replacement
1. Be sure to clean and dry the areas around the charging port and water sensors after every use to avoid the forming of
2. Battery discharges on its own during storage. Make sure to charge the robot to about 30% to 50% of the battery capacity
• Be sure to drain the water from the robot before storage.
temperature for storage should be 10˚C – 25˚C ( 50˚F – 77˚F ).
- Battery does not charge fully.
Battery operation time is noticeably reduced. Observe and record the run times of the first few operations ( on a full charge ).
could cause sparking and/or short circuit the battery.
Follow section “
2. Use the screwdriver to unscrew the 4 screws located at the bottom of the head to release the
3. Remove out the battery pack to expose the PCBA. To detach the battery connection wire, press
2021/10 : AMAINTENANCE & CLEANING
bwt.com
ENGLISH
OFF
ON
5-6h
RED light - Charging
GREEN light - Charged
3/147
