Congratulations on your purchase of a Bushnell
®
AR Optics
™
riflescope! You are now the owner of one of the most
technologically advanced riflescopes in the industry. Bushnell maintains absolute product integrity and quality control
throughout the entire design, production, and delivery cycle of these riflescopes.
WARNING: NEVER LOOK AT THE SUN THROUGH THE RIFLESCOPE (OR ANY OTHER OPTICAL INSTRUMENT).
IT MAY PERMANENTLY DAMAGE YOUR EYES.
AR OPTICS RIFLESCOPE FEATURES
Bushnell® is constantly at the forefront of quality and value, and AR Optics™ riflescopes are designed specifically for the
AR platform, delivering maximum accuracy and reliability to master every tactical scenario. There is a scope for every
popular caliber, including 22 LR, .223/5.56, .308, 300 Blackout, and even 6.5 Creedmoor. Fully-Multi Coated Optics and
waterproof construction offer crisp, bright images in every environment. Many models include our PCL Throw Down Power
Change Lever with interchangeable short and long handles, making these scopes as customizable as the rifles they share
a name with. The new lineup of AR Optics™ riflescopes from Bushnell® won’t disappoint.
All AR Optics riflescope models feature:
• CLARITY - The best resolution and contrast in all lighting conditions
• WIDE RANGE OF MODELS - Multiple configurations, turret types, tube diameters and reticles to cover every situation
and user preference.
• SPECIAL FEATURES- Selected models offer illuminated reticles and our PCL “Throw Down” Power Change Lever.
• HIGH LIGHT TRANSMISSION - Ultra Wide Band Coating enables optimum brightness and true color in every lighting
condition.
CARING FOR YOUR RIFLESCOPE
Your scope needs very little maintenance. Exterior metal surfaces should be kept clean. A light dusting with a slightly
dampened soft cloth is enough in most cases.
Your new scope features windage and elevation turrets that are completely sealed against water intrusion. However, we
recommend that you keep the windage and elevation caps on the turrets (models with capped adjustments only), except
when making adjustments, to prevent dust and dirt from collecting in the turret area.
We also recommend that lens covers be kept in place when the scope is not being used. Lenses should be inspected
regularly and kept clean at all times. Dust, dirt, and fingerprints that collect on the lens surfaces will severely degrade
image quality, and if left unclean for long periods, the anti-reflection coating could be damaged. Although lens cleaning
is not difficult, it does require care and some patience.
• Start with a lens brush or a small, soft bristle paintbrush. Gently whisk away loose dirt particles.
• Next, use an ear syringe or bulb aspirator (available in most drug stores) to blow remaining dirt or dust from lens
surfaces.
• If further cleaning is needed, use a dry, soft lint-free cloth. Very gently wipe the lens, starting at the center using a circular
motion, then working outward to the edge.
• If this has not corrected the problem repeat the process using condensation from your breath.
KEY ELEMENTS OF A SCOPE
There are four major elements of a scope:
1. Objective Lens: This lens has three functions. First, it permits light to pass into the scope. Second, it determines
resolution. Generally, larger lenses allow more light to enter the scope and resolve details better than smaller ones.
Finally, it forms an image for the other lenses to magnify to a usable size. The image formed by this lens is upside down.
2. Erector System: The erector system serves three functions. Its primary function is to erect the image (that is, flips the
image right-side up) and align it to the reticle. During this process, primary magnification of the image takes place.
These two functions are the result of lens action.
The third function is a mechanical one. The erector lenses are housed in a tube that is fixed at one end, while the other
end of the tube is free to move and respond to dial adjustments. By moving the erector system, the point-of-aim of the
scope is adjusted to match the point-of-impact of the bullet.
3. Reticle: In simple terms, the aiming device around which the scope is built. This element replaces the iron sight system
of non-scoped rifles.
4. Ocular or Eye Lens: This element provides the secondary and final magnification of the image.
