15
Special Instructions for Model# AR741840E / AR741840EI (4.5-18x40 w/interchangeable elevation turret knobs)
Model# AR741840E and AR741840EI (illuminated version) include these four additional BDC elevation turret knobs:
• (1) 223 Rem
• (1) 308 Win
• (1) 6.5 Creedmoor
• (1) 224 Valkyrie
A standard 0.1 Mil click turret (6 Mils per rev) is pre-installed.
To switch to any of the optional elevation turrets:
1. Before starting, sighting-in the scope with the pre-installed standard turret
set to the “0” position is recommended (Fig. A).
2. Using the provided tool, loosen the three hex bolts located around the top
rim of the standard turret (Fig. A, arrows).
3. Remove the standard turret, lifting it straight up. The brass elevation
adjustment post is exposed (Fig B). Set the standard turret aside in a safe place.
4. Replace the standard turret with the one that matches your load type (see tables
on next page) and press it down into position onto the brass post, with the 100
yard mark on the turret lined up with the index mark on the scope (Fig C).
5. Secure the new turret in place by tightening the three hex bolts with the provided
tool (Fig C, arrow).
6. Sight-in and zero the turret knob (at 100 yds), loosening the hex bolts and
rotating the turret knob as needed for proper calibration at the 100 mark, then
retightening the hex bolts.
Fig. B
Fig. B
Fig. A
Fig. C
Fig. C
Standard .1 Mil Turret Reference
1. 3.4377 MOA per 1 mil
2. At 100 yards distance
• 1 mil = 3.599 in
• 0.1 mil = 0.3599 in ≈0.36 in
• 1 moa = 1.047 in
• 1/4 moa = 0.262 in
3. At 100m distance
• 1 mil = 10 cm
• 0.1 mil = 1 cm
