5
Installation of Front Mounting Plate
Place the cross bolts where needed for mounting scope with
correct eye relief.
Be sure the slot of the plate lies over the Front Cross Bolt. Rock the
scope into place.
Be sure the side clamps engage the rails and finger tighten the nuts.
Push the scope forward until there is firm metal to metal contact on
the Rear Cross Bolt. Firmly tighten both hex nuts to 50 to 70 inch/
pounds.
Eyepiece Focusing
The eyepiece can be focused so the reticle appears sharp and
black to any individual’s eye. Follow this procedure to quickly
adjust the focus:
Point the scope at the sky or a plain wall, and take a quick glance
through the scope. If the reticle appears sharp and black, no further
adjustment is necessary.
1
Front Cross Bolt
assembly with Plate
Rear Cross
Bolt assembly
