Select a Weaver-style or Picatinny-style mounting base. We
recommend the use of Burris Xtreme Tactical Bases, as they were
designed to accommodate the Eliminator 5.
Read the
manufacturer’s
directions regarding
the installation of mounts
before beginning.
Clean the mounting area of the
rifle with a chemical that removes
grease and oil. Pay special attention to the screw holes.
Use the same chemical to clean the mounts. Do not allow the
cleaning chemical to come in contact with the stock or scope lenses.
After installing the base, position the scope so it offers the proper
eye relief. To do this, shoulder the rifle as you would in the field.
Dial to the highest magnification and position the scope as far
forward as possible while achieving a full field of view.
Note the two slots in the base or bases you will use to attach the
scope. With the mount clamps fully open, place the mount bolts
into the slots on the base. Now match up the Eliminator 5 scope
slots and place over the two mount bolts—rocking the scope side to
side until the scope is flush with the base. The mount clamps should
grip the lip of the base and the lip of the rail on the underside of
the scope. Finger tighten only.
With hex nuts slightly loosened, push the
scope forward, and then firmly tighten both
hex nuts to 50 to 70 in./lbs.
Front Mounting Plate Instructions
If you are using a tapered base, or are having difficulty sighting-
in at 100 yards because of a lack of down elevation adjustment,
this Front Mounting Plate will put you on target.
For your convenience, three plate sizes are included:
A) Approx. 10 MOA adjustment down
B) Approx. 20 MOA adjustment down
C) Approx. 30 MOA adjustment down
– Typical Mounting Situation –
Use the Front Mounting Plate as shown on next page:
1
2
3
4
5
6
I. MOUNTING THE
ELIMINATOR 5
Burris Xtreme Tactical Base
