15
4. CONTROLS (Cont’d)
4.2 WAll COnTROl(S) ElECTRiCAl COnnECTiOn (COnT’d)
CONT
VQ0137
When used, the VBATHW activation will override the main control operation, as well as the unit
defrost cycle. On example shown on the left, the unit was in CONT mode when the auxiliary
control was activated; so the actual operation mode stays on VT9W main wall control screen,
but the chronometer icon appears as long as the VBATHW is activated.
NOTE: In colder regions, the chronometer icon may stay after the end of the VBATHW cycle,
due to defrost cycle.
4.2.2 ElECTRiCAl COnnECTiOn TO VBATHW OPTiOnAl AuxiliARy COnTROl(S)
VC0237
Up to five (5) VBATHW auxiliary controls can be installed.
NOTE: The auxiliary wall control can be used with a 3-wire
connection by removing the LED signals. This optional wiring
will not allow an installation with more than 1 auxiliary wall
control to properly synchronize their LEDs on an event
requested from a peer. Only the auxiliary wall control having
requested the timer event will have the LEDs updated
accordingly.
