9
3.1.2 UNDER CEILING OR WALL MOUNTED
1. Using 4 screws no. 8-18 x 0.375 in., install the brackets on the unit as illustrated in Figure A. DO NOT
USE OTHER SCREWS.
2. Using 4 screws no. 10-12 x 0.625 in. or longer screws if necessary, secure the unit to the wall or
ceiling, into the studs, joists or other solid material.
💡 When wall mounted, the unit can be positioned in any orientation to suit your need.
3.1.3 CEILING HUNG
The brackets have been designed to allow that the unit be hung using threaded rods.
1. Using 4 screws no. 8-18 x 0.375 in., install the brackets in one of both ways illustrated below. DO NOT
USE OTHER SCREWS. Use nuts to secure the unit.
3.1.4 IN THE ATTIC
CAUTION
Do not install in an attic where the temperature may exceed 160 °F.
1. Using 4 screws no. 8-18 x 0.375 in., install the brackets on the unit as illustrated above in Figure A.
DO NOT USE OTHER SCREWS.
2. Using 4 screws no. 10-12 x 0.625 in., secure the unit to the joists or cross framing.
Figure A: Bracket installation
VD0468
VD0465
OR
VD0469
