AWT35-100109 Rev AB 19/29
CODE
Do not use.
VOL
Checking the voltage: the indicator board voltage is shown U X.X（V）
VER
Checking the version: the indicator software version is shown
5.3 Calibration Menu
The SBI 210-LCD is configured from the factory to match the specified settings for each unit, as defined
by the product specifications and sales brochure. Modification of the settings can be accomplished by
altering the calibration settings below.
Calibration and/or configuration of calibration settings of your scale should be
accomplished by a trained service technician using certified weights to ensure proper
operation and accuracy. Calibration is not covered under warranty.
5.3.1 Calibration Options
In general weighing mode, press the TARE and ZERO/ON/OFF keys. Release the keys when the
“CAL” message pops up to open the Calibration Menu. The number of calibrations is shown.
Navigate the menu using the keys, press the TARE key to confirm or the ZERO/ON/OFF
key to cancel the operation / exit the menu.
CAL
SubMenu1 SubMenu2 Option Description
ZERO
Adjusts the CAL.P0 point only.
LINE
CAL.P0
Stores the Zero calibration point (mandatory).
CAL.P1
Adds the cal. point 1 (mandatory). Use a
standard weight over 10% F.S.
END.Y
YES / NO
Saves and exits the calibration points:
Yes = go to CAL.END;
No = add another calibration point
CAL.P2
Adds the cal. point 2 (optional). Use a standard
weight over 10% F.S. and load used in CAL.P1.
END.Y YES / NO
Saves and exits the calibration points:
Yes = go to CAL.END;
No = add another calibration point
CAL.P3
Linear calibration point3: do third weight point
calibration, standard weight must be over
10%FS and be larger than it in CAL.P2, this
point can be omitted.
GEO
01-32
Default = 16. See table below.
