AWT35-501860 Issue AE.1 Page 18
4.1.2. User Functions Descriptions [UF]
There are 9 Setup Functions.
UF-1
Diagnostic: use this menu to check or verify the performance of the indicator. The
diagnostic tests available include: Scale A to D to view output from the connected scale
base or load device, Internal D-Value, and Battery Voltage.
UF-2
Checkweighing: the acceptable weight is any weight which falls between the upper and
lower limits. Enter this option to set the items relating to checkweighing:
• LOW / HIGH limits. Valid beeper modes: o 000; o 001; o 002.
See chapter 3.4. Checkweighing Mode on page 13.
UF-3
Auto Power-Off: use this to set the length of time before the scale automatically turns
off if not being used. Values can be set between 01 and 99 minutes.
Factory default: AoFF 10 (10min). Auto Power-OFF is disabled when AoFF 00
UF-4
Backlight: use this to set the light mode:
• OFF / Automatic / ON
Factory default: Lit A (automatic)
UF-5
Hold / Animal Weighing Mode: use this to enable and configure the Hold parameters:
• Hold 0 / Hold 1
Factory default: Hold 0 (disabled)
See chapter 3.5 Hold Mode on page 24.
UF-6
RS232 Output: use this to configure the communication port items:
• Format 1 or 2: STABLE / STREAM / MANUAL mode and baud rates.
Factory default: 232 0 (disabled)
See chapter 7. RS232 Communications on page 24.
UF-7
ADC Update Rate: use this to select the sampling frequency: 15 (1), 30 (2) or 7.5Hz (3)
See LF 4, Supervisor Functions Descriptions
UF-8
Zero Tracking: use this to define a ±0 /5div range around zero. When the scale weight
is not at the center of zero but inside this range, ½ of the weight will be subtracted until
the weight is inside the center of zero region.
See LF 5, Supervisor Functions Descriptions.
UF-9
Gravitational value: use this item to key in a gravity constant value.
CAUTION! This item is locked when the calibration switch is at position OFF.
See LF 7, Supervisor Functions Descriptions and chapter 6. Calibration on page 22.
