24
1. Unplug the AC Adapter from the wall outlet and
machine.
It may be helpful to remove the Outside Shroud in
order to observe the movement of the Resistance
Shoe.
If removing the Outside Shroud continue to Step 2.
If not removing the Outside Shroud go to Step 3.
2. Carefully remove the left Outside Shroud, using
small flathead screwdriver (or auto trim tool) to
disengage the inside tabs from the Main Assembly.
Note: To avoid damage to the surface of the Shrouds,
we recommend putting a piece of cloth over the screw-
driver blade.
Set the Outside Shroud safely aside for reassembly.
NOTICE: Do not touch the Base Hub PCBA.
Note: Your machine may not match the images provided exactly.
Left outside shroud - tab locations Removing left outside shroud (Pedal not shown)
Resistance shoeResistance shoe
Base Hub PCBA
