22
4. Check the Drive Belt tension:
• Push the Drive Belt downward at the midpoint (M)
between the pulleys and measure the distance. The
Drive Belt should have only 0.25” (0.64 cm) of give.
Or:
• Hold the edges of the Drive Belt at the
midpoint (M) and twist it. It should turn
only 90 degrees (1/4 turn, to vertical).
5. Using a 13 mm wrench, adjust the
Tensioning Bolt.
If the Drive Belt is too loose—turn the Nut
on the Tensioning Bolt clockwise.
If the Drive Belt is too tight—turn the Nut
on the Tensioning Bolt counterclockwise.
6. Check the belt tension:
If the tension is correct—continue to step 7.
If the tension is not correct—repeat step 5.
Checking Belt tension (Flywheel bracket and inner
shroud not shown)
8. Put the Outside Shroud in position and press to
engage the tabs. Be sure the Shroud is securely
attached.
9. Final Inspection
Inspect your machine to ensure that all hardware is tight and components are properly assembled.
Do not use until the machine has been fully assembled and inspected for correct performance in
accordance with the Owner’s Manual.
7. Get on the bike and check the movement of the
Drive Belt by rocking back and forth on the pedals.
The Pedals and Flywheel should move as one.
Adjust the Drive Belt tension again if necessary.
M
Tensioning bolt
Drive pulley
Flywheel pulley
Idler pulley
Drive belt
