Panel descriptions
* To prevent malfunction and equipment failure, always turn down the volume, and turn off all the units before making any connections.
Number Name Explanation
1 DC IN jack Use this jack to connect a separately sold AC adaptor (PSA-S series). By using an AC adaptor, you
can play without being concerned about how much battery power you have left.
* Use only the specified AC adaptor (PSA series; sold separately), and connect it to an AC
outlet of the correct voltage.
* If the AC adaptor is connected while power is on, the power supply is drawn from the AC
adaptor.
2 CHECK indicator This indicator shows whether an effect is ON/OFF, and doubles as the Battery Check indicator.
The indicator lights when an effect is ON. You can check whether the effect is on or off.
* The brightness of the CHECK indicator (LED) will dim as the battery lowers. Replace the
battery when the LED is dim or does not light. For details on how to replace, refer to
“Replacing the battery (p. 8)”.
3 [BALANCE] knob Adjusts the balance between the effect sound and the direct sound.
4 PEDAL MODE [TOGGLE/MOMENT]
switch
Selects how the pedal switch operates.
TOGGLE: The effect toggles between on and off with each press of the pedal.
MOMENT: The effect turns on only while the pedal is pressed.
5
SHIFT DIRECTION [É/DETUNE/Ç]
switch
Sets the direction of pitch shift.
É(down): The pitch shifts down.
DETUNE (center): Adds a detuned sound to the input audio.
Ç(up): The pitch shifts up.
