Preventing material damage en
Burner NG
Hourly gas con-
sumption (MJ)
NG
Injector mark
ULPG
Hourly gas con-
sumption (MJ)
ULPG
Injector mark
High-output burner 11.0 153 9.70 87
Dual-wok multi-crown
burner
19.50 Outer flame: 190
Inner flame: 77
16.00 Outer flame: 100
Inner flame: 45
Replacing the injectors
Replace the nozzles using the appropriate wrench
and tighten them carefully to guarantee the seal.
Ensure that the nozzle does not become detached
during removal or fastening.
Reinstalling the appliance
Install the appliance components in reverse order.
Checking if equipment is working
1.
Check that turning the rotary knob between the posi-
tion for maximum power and the position for min-
imum power does not cause the burner to go out or
result in backfire.
2.
If the gas flow from the burner is not correct, check
whether the nozzle and the position of the bypass
screw are correct.
"Adjusting the taps", Page10
Documenting the gas type conversion
Attach the sticker showing the new gas type near to
the rating plate.
Preventing material damage3 Preventing material damage
ATTENTION
Heat can cause damage to adjacent appliances or kit-
chen units.
If the appliance is in operation for an extended period,
heat and moisture will be generated.
Open a window or switch on an extractor hood lead-
ing to the outside.
A build-up of heat may damage the appliance.
Do not use two burners or heat sources to heat one
single item of cookware.
Do not use griddle plates, clay pots, etc. for a long
time at full power.
Do not use large pots or heavy weights that can
bend the pan support or deflect flame onto the cook-
top.
Do not remove the pan support and enclose the
burner with a wok stand as this will concentrate and
deflect heat onto the cooktop.
Do not place anything, for example, flame tamer or
asbestos mat, between pan and pan support as seri-
ous damage to the appliance may result.
A build-up of heat may damage the controls.
Do not use a large item of cookware on burners that
are close to the control knobs.
If a control knob is in the wrong position, this could lead
to malfunctions.
Always turn the control knob to the "Off" position
when the appliance is not being used.
Handling the cookware roughly may damage the sur-
face of the appliance.
Handle the cookware on the cooktop carefully.
Moving the cookware may scratch the glass.
Lift the cookware when moving it.
Damage may occur if hard or pointed objects fall on the
cooktop.
Do not let hard or pointed objects fall onto the cook-
top.
Do not bump into any of the edges of the cooktop.
Salt, sugar or sand that may fall from the vegetables will
scratch the glass.
Do not use the cooktop as a work surface or storage
space.
Melted sugar or food with a high sugar content may
damage the glass.
Remove boiled-over food immediately with a glass
scraper.
11
