8
3. Turn the hob around and insert it into the recess.
Insert the hob in the front of the recess.
→Fig.
7
4. Turn the brackets and tighten them fully.
→Fig.
8
The position of the brackets depends on the work-
top thickness.
Note:Do not use silicone to bond the appliance to
the worktop.
Removing the appliance
1. Disconnect the appliance from the electricity and
gas connections.
2. Unscrew the brackets and proceed in reverse or-
der.
Connecting the gas
Observe the country-specific guidelines.
CAUTION‒Risk of explosion!
A gas leakage may cause an explosion.
▶
If any connection is handled, check the seal.
¡ Arrange the gas connection so that the shut-off
valve is accessible.
¡ Ensure that the information on the rating plate re-
garding the gas type and gas pressure complies
with the local connection conditions.
¡ Connect the appliance to a fixed gas pipe or a flex-
ible metal pipe.
¡ The flexible metal pipe must not come into contact
with the moving parts of the unit in which the appli-
ance is installed (e.g. a drawer) and must not be
routed through any spaces which might become ob-
structed.
¡ Gas connection on the appliance: G 1/2.
Connection to gas cylinder or liquid gas tank
▶
If the flame is large or unstable, check that the
regulator of the gas cylinder or liquid gas tank is
working properly.
Note:You can install an overpressure safety device
that limits or cuts off the gas supply if the regulator
of the gas cylinder or liquid gas tank fails.
Spare parts for gas connection
If the country's regulations allow, you can obtain the
gas connection parts from the technical customer
service.
→Fig.
9
Gas connection R 1/2
▶
Fit the seal and the connecting piece R 1/2 to the
gas connection on the appliance.
→Fig.
10
Gas connection G 1/2
▶
Insert the seal between the gas connection of the
appliance and the gas supply.
→Fig.
11
Electrical connection
¡ This appliance is type Y: The connection cable must
only be replaced by technical customer service and
not by the user. The cable type and the minimum
cross section must be respected.
¡ The hobs are supplied with a power cord with or
without a plug.
¡ The power cable must only be replaced with a cable
from the original manufacturer. This is available
from after-sales service.
¡ Do not use extension cables or multiple socket
strips.
¡ Only connect appliances that are fitted with a plug to
a correctly installed socket with protective earth con-
ductor.
¡ Connect the appliance to a fixed installation and set
up appropriate isolating switches in accordance with
the installation regulations.
→Fig.
12
¡ BN: Brown
¡ BU: Blue
¡ GN/YE: Green and yellow
Converting the gas type
If the country's regulations allow, this appliance can
be adapted to other types of gas, if these are listed
on the rating plate.
You can find the right parts in the bag that is sup-
plied with the appliance or you can obtain them from
customer service. The table shows the right combin-
ation for the relevant burner and gas type.
Dual-wok multi-crown burner
¡ 1-Outer flame
¡ 2-Inner flame
Adjusting the taps
1. Set the control elements to the minimum power
level and pull them out.
2. To access the bypass screw, use the tip of the
screwdriver to push down on the flexible rubber
holder.
→Fig.
13
Never remove the sealing ring. Sealing rings pre-
vent liquids and dirt from finding their way into the
appliance and impairing its ability to function prop-
erly.
3. When adjusting the bypass screws (M), refer to
the table →Fig. .
‒ A: Firmly tighten the bypass screws.
‒ B: The bypass screws must be flush with the fit-
ting.
→Fig.
14
Removing the upper part of the appliance (glass
plate with cut-out profiles)
1. Remove the pan supports, burner caps, distribut-
ors and rotary knobs.
2. Undo the screws on the burners.
→Fig.
15
3. Move the removal lever under the metal cut-out
profile into the area marked for the hob model
and loosen the front clip fastener.
→Fig.
16
Only use the lever under the cut-out profiles or the
metal frame of the hob.
4. Carefully lift the glass plate with the cut-out pro-
files to release the rear clip fastener.
Replacing the nozzles
1. Remove all pan supports, burner caps and distrib-
utors.
2. Replace the nozzles using the appropriate wrench
and tighten them carefully to guarantee the seal.
Ensure that the nozzle does not become detached
during removal or fastening.
Replacing the outer flame nozzle on the multi-crown
burner
Requirement:The upper part of the appliance has
been removed.
1. To gain access to the main nozzle, loosen the
fastening screw and pull the sleeve back.
→Fig.
17
