Preparing the furniture item for flush installation
¡ All cutting work on the work surface must be car-
ried out in a specialist workshop.
¡ The cuts must be clean and precise because the
cutting edge is visible on the surface. The stability
of the units must also be ensured after the cutting
work.
¡ Only use special, temperature- and water-resistant
work surfaces (e.g. natural stone or tiles).
¡ The fitted unit must be heat-resistant up to 90°C.
Positioning the appliance
Note:Do not use silicone to bond the appliance to
the worktop.
1. Position the hob with the upper side facing down
on a flat, stable surface.
2. Apply the adhesive seal supplied to the lower
edge of the hob. The adhesive seal prevents the
penetration of liquids.
→Fig.
6
3. Screw the brackets supplied into the specified po-
sition so that they can turn freely.
→Fig.
7
4. Turn the hob around and insert it into the recess.
Insert the hob in the front of the recess.
→Fig.
8
5. Turn the brackets and tighten them fully.
→Fig.
9
The position of the brackets depends on the work-
top thickness.
Installing the appliance flush
1. Install the appliance so that there is an even gap
all around it. →"Positioning the appliance",
Page8
‒ The hob should be slightly below the work sur-
face. On tiled worktops, the contact surfaces
can be raised, if necessary, with temperature-
and water-resistant rails.
→Fig.
10
2. Check that the appliance works correctly and is in
the correct position.
3. Fill the gap between the work surface and the hob
using a suitable commercially available silicone
adhesive.
→Fig.
11
Smooth the silicone adhesive with a spatula or a
finger wetted with soap before a solid layer forms.
Note:Leave the silicone adhesive to dry before you
use the appliance.
Tip:If you use an unsuitable silicone adhesive on
natural stone work surfaces, it may cause discolour-
ation that can no longer be removed. A suitable ad-
hesive is available from our technical customer ser-
vice.
Removing the appliance
1. Disconnect the appliance from the electricity and
gas connections.
2. Unscrew the brackets and proceed in reverse or-
der.
Connecting the gas
Observe the country-specific guidelines.
CAUTION‒Risk of explosion!
A gas leakage may cause an explosion.
▶
If any connection is handled, check the seal.
¡ Arrange the gas connection so that the shut-off
valve is accessible.
¡ Ensure that the information on the rating plate re-
garding the gas type and gas pressure complies
with the local connection conditions.
¡ Connect the appliance to a fixed gas pipe or a
flexible metal pipe.
¡ The flexible metal pipe must not come into contact
with the moving parts of the unit in which the ap-
pliance is installed (e.g. a drawer) and must not
be routed through any spaces which might be-
come obstructed.
¡ Gas connection elbow on the appliance: R 1/2.
¡ Do not move or twist the gas connection elbow.
Connection to gas cylinder or liquid gas tank
▶
If the flame is large or unstable, check that the
regulator of the gas cylinder or liquid gas tank is
working properly.
Note:You can install an overpressure safety device
that limits or cuts off the gas supply if the regulator
of the gas cylinder or liquid gas tank fails.
Spare parts for gas connection
If the country's regulations allow, you can obtain the
gas connection parts from the technical customer
service.
→Fig.
12
Gas connection R 1/2
→Fig.
13
Gas connection G 1/2
1. Replace the gas connection elbow on the appli-
ance with the gas connection elbow G 1/2 sup-
plied in the accessory bag.
→Fig.
14
2. Insert the seal between the gas connection of the
appliance and the gas supply.
→Fig.
15
Electrical connection
¡ This appliance is type Y: The connection cable
must only be replaced by technical customer ser-
vice and not by the user. The cable type and the
minimum cross section must be respected.
¡ The hobs are supplied with a power cord with or
without a plug.
¡ The power cable must only be replaced with a
cable from the original manufacturer. This is avail-
able from after-sales service.
¡ Do not use extension cables or multiple socket
strips.
¡ Only connect appliances that are fitted with a plug
to a correctly installed socket with protective earth
conductor.
¡ Connect the appliance to a fixed installation and
set up appropriate isolating switches in accord-
ance with the installation regulations.
→Fig.
16
¡ BN: Brown
¡ BU: Blue
¡ GN/YE: Green and yellow
Converting the gas type
If the country's regulations allow, this appliance can
be adapted to other types of gas, if these are listed
on the rating plate.
You can find the right parts in the bag that is sup-
plied with the appliance or you can obtain them from
customer service. The table →Fig.
20
shows the
right combination for the relevant burner and gas
type.
Economy burner
