‒ B: Die Bypass-Schrauben drehen, bis der Gas-
austritt aus den Brennern korrekt ist.
Düsen austauschen
1. Roste, Brennerdeckel und Verteiler abnehmen.
2. Die Düsen mit dem passenden Schraubenschlüs-
sel wieder einsetzen und sorgfältig festziehen, um
die Dichtigkeit zu gewährleisten.
→Abb.
18
, →Abb.
19
Darauf achten, dass sich die Düse bei der Abnah-
me oder der Befestigung nicht löst.
Gerät wieder einbauen
▶
Die Gerätekomponenten in umgekehrter Reihen-
folge wieder einbauen.
Funktionstüchtigkeit prüfen
1. Prüfen, ob das Drehen des Drehknopfes zwischen
der Position für maximale Leistung und der Positi-
on für minimale Leistung nicht zum Erlöschen des
Brenners oder zu einer Rückzündung führt.
2. Wenn der Gasaustritt des Brenners nicht korrekt
ist:
‒ in der Tabelle →Abb.
20
prüfen, ob die Düse
und die Bypass-Schraube die korrekten sind.
‒ Die Bypass-Schraube festziehen oder lösen, bis
der Gasaustritt aus dem Brenner korrekt ist.
Umstellung der Gasart dokumentieren
▶
Den Aufkleber mit der Angabe der neuen Gasart
in der Nähe des Typenschilds anbringen.
en
Safe installation
Follow these safety instructions when installing the
appliance.
¡ Read this instruction manual carefully.
¡ The images shown in these instructions are for
guidance only.
¡ The appliance can only be used safely if it is cor-
rectly installed according to the safety instructions.
The installer is responsible for ensuring that the
appliance works perfectly at its installation loca-
tion.
¡ Once you have established the connections, carry
out a test for leaks.
WARNING‒Risk of explosion!
Escaping gas may cause an explosion.
▶
All Installation, connection, regulating and conver-
sion work to a different gas type must be carried
out by an authorised professional while taking into
account the respective applicable regulations and
legal requirements as well as the regulations re-
garding the local electricity and gas suppliers.
Special attention must be paid to the provisions
and guidelines that are applicable for the ventila-
tion. For conversion work to a different gas type,
we recommend that you call the after-sales ser-
vice.
¡ Ensure that the kitchen is sufficiently ventilated, in
particular when operating the gas cooking appli-
ance.
¡ Do not connect the appliance to an exhaust gas
system for combustion products.
¡ Never install the appliance in boats or in vehicles.
¡ The warranty applies only when using the appli-
ance as intended.
¡ Before installing the appliance, check that the
local conditions of the supplier are compatible
with the appliance settings specified on the rating
plate (type of gas and pressure, power, voltage).
¡ Secure the power cord to the cabinet to prevent it
from touching hot parts of the oven or hob.
¡ Before any work is carried out on the appliance,
switch off the power supply and the gas supply.
¡ Connect the appliance to the power supply using
the earth.
¡ Do not make any changes to the inside of the ap-
pliance. If required, contact our technical cus-
tomer service.
Before installing
¡ This appliance is a class 3 appliance in accord-
ance with the EN 30-1-1 standard for gas appli-
ances: Built-in appliance.
¡ The unit in which the appliance is installed must
be stable and secured appropriately.
¡ The units in the vicinity of the appliance, the lamin-
ated panels and the adhesive with which they are
secured must be made of non-flammable, heat-
resistant materials.
¡ Do not install this appliance above refrigerators,
washing machines, dishwashers or similar.
¡ The appliance must only be installed on an oven
with forced ventilation. Check the dimensions of
the oven in the installation instructions for the
oven.
¡ If you install an oven underneath the hob, the work
surface thickness may differ from the dimensions
given in these instructions. Take note of the in-
formation in the oven installation instructions.
¡ If you install an exhaust air fan or an extractor
hood, refer to the installation instructions for these.
Always observe the minimum vertical distance to
the hob.
→Fig.
1
Preparing the units
¡ Make a cut-out in the worktop with the required di-
mensions depending on the relevant installation
method: Standard (a) or flush (b).
→Fig.
2
¡ Any panel that is attached closer to the built-in
niche than the specified clearance must be made
of non-combustible material. Always maintain a
distance of at least 5mm between the panel and
the appliance. Maximum clearances for the panel:
30 mm thickness x 70 mm height.
¡ Seal the cut surfaces of wooden work surfaces
with a special glue seal to protect them from mois-
ture.
WARNING‒Risk of burns!
The accessible parts may become hot during opera-
tion.
If there is no built-in oven underneath the hob and
the underside of the hob is accessible, follow these
instructions:
For gas hobs with wok burner, insert a non-flamable
intermediate floor (e.g. metal or ply-Wood) at a dis-
tance of 10 mm from the hob .
→Fig.
3
For gas hobs without a wok burner, it is advisable to
fit an intermediate floor underneath the hob .
→Fig.
4
In both cases, the distance from the intermediate
floor to the mains connection for the appliance must
be at least 10 mm.
The thickness of the separator must allow for re-
specting the distances in the figure.
Installation above an oven
→Fig.
5
