English | 19

– Overheated electrical components (e.g. fuses or termin-

als)

– Faulty or damaged machine parts (e.g. overheating due to

faulty ball bearings)

The measuring tool is not suitable for measuring the temper-

ature of gases.

The measuring tool must not be used for human medical pur-

poses.

Please find out about veterinary application at

www.bosch-professional.com/thermal.

The measuring tool is suitable for indoor and outdoor use.

This product is a consumer laser product in accordance with

EN50689.

The light of this measuring tool is intended to illuminate the

direct work area of the measuring tool in order to take pic-

tures and is not intended as a continuous work light.

The laser point must not be used as a laser pointer. It is

solely for marking out the area being measured.

Product Features

The numbering of the product features shown refers to the il-

lustration of the measuring tool on the graphic page.

(1)

Protective cap

(2)

Laser beam outlet aperture

(3)

Visual camera

(4)

Worklight

(5)

Infrared sensor

(6)

Pause/start measurement button

(7)

Battery bay

(8)

Laser warning label

(9)

Coin cell holder

(10)

Coin cell holder screw

(11)

Flap for USB port and coin cell holder

(12)

USB Type-C® port

(13)

Laser button

(14)

Rechargeable battery/battery adapter release button

(15)

Rechargeable battery

(16)

USB Type-C® cable

(17)

Multi-function button

(18)

On/off button/Back button

(19)

Display

(20)

Serial number

(21)

Battery adapter cover

(22)

Batteries

(23)

Battery adapter cap

a) USBType-C® and USB-C® are trademarks of USB Implementers

Forum.

The accessories illustrated or described are not included as

standard delivery.

Display Elements

(a)

Emissivity indicator

(b)

Reflected temperature indicator

(c)

Average temperature indicator

(d)

Memory full symbol

(e)

Worklight symbol

(f)

Laser symbol

(g)

Battery charge indicator

(h)

Maximum surface temperature in the measuring

range indicator

(i)

Scale

(j)

Minimum surface temperature in the measuring range

indicator

(k)

Fix temperature scale symbol

(l)

Cold spot indicator (example)

(m)

Crosshairs with temperature indicator

(n)

Hotspot indicator (example)

(o)

Menu symbol

Technical Data

Thermal imaging camera GTC 12V-450-13

Article number

3601K83900

Resolution of infrared sensor 256×192px

Thermal sensitivity

≤50mK

Spectral range 8–14μm

Field of view (FOV)

55.6°×42°

Spatial resolution (IFOV) 3.79mrad

Focus distance

≥0.5m

Focus Fixed

Thermal image refresh rate ≤9Hz

Surface temperature measuring range

–20°Cto+450°C

Bosch Power Tools 1 609 92A 9ZG | (14.01.2025)
