English | 25

To avoid electric shocks, injuries or damage to the

measuring tool before performing resistance or

continuity tests, ensure that the mains power connection

is disconnected and all high-voltage capacitors are dis-

charged.

Measuring functions

The measuring tool offers the following measuring func-

tions:

– Measurement of alternating current

– Measurement of resistance

– Continuity test

– Measurement of alternating voltage

– Measurement of direct voltage

Measuring Process

u Use for measurements always the proper input ter-

minals, switch position and measuring range.

u Check the test leads for continuity before use. Do

not use if the readings are high or noisy.

u Keep your fingers behind the finger guards while

using the test leads.

Turn the rotary switch(3) to the position in the figure.

When Using Test Leads:

Connect test leads(10) and(9) as shown in the fig-

ure.

Contact the test points with the test probes.

The measured value is shown on the display(1).

When Using the Measuring Clamp:

Push the lever(2) to open the measuring clamp(5).

Enclose the cable to be measured with the measuring

clamp(5) and close the measuring clamp by releasing

the lever(2).

The measured value is shown on the display(1).

Measurement of Alternating Current (see Fig. A,

page4) (see Fig. B, page4)

u Keep your fingers behind the finger guard when us-

ing the measuring clamp.

u Do not take any measurements if the open-circuit

potential to earth is more than 600V.

Take the measurement with the measuring clamp (see

"Measuring Process", page25).

Measurement of resistance(see Fig. C, page4)

Take the measurement with the test leads (see "Meas-

uring Process", page25).

Continuity test(see Fig. D, page4)

Take the measurement with the test leads (see "Meas-

uring Process", page25).

If the continuity test is successful, a continuous

tone is output.

Bosch Power Tools 1 609 92A A6W | (20.01.2025)
