34 en | Configuration

FLEXIDOME panoramic 5100i | FLEXIDOME

panoramic 5100i IR

2024-11 | V03 | F.01U.385.628

User manual

Bosch Security Systems B.V.

5.4.10 Encoder Streams

When this menu is accessed while the device is recording, the following message appears at

the top of the page: “Recording is currently active. At ‘Active profile’ the stream profile used

for recording is displayed, and overrules the ‘Non-recording profile’.”

If the application variant is set to dewarp, more options appear at the top of the page.

You are able to select between:

– Video 1 Full Image Circle

– Video 2 Dewarped view mode

– Video 3 E-PTZ

Stream limits (H.264/H.265)

This option is only available in Video 1 Full Image Circle.

In the dropdown, select the maximum stream resolution as provided per stream.

Stream limits is a mandatory selection to pre-assign the maximum available resolution for

each of the four H.264 / H.265 streams. If a lower resolution is selected, you will be more

flexible in streaming options on the second and third stream. The fourth JPEG stream

always shows the maximum resolution available in the camera.

The stream limits may be automatically balanced to ensure frame rate distribution through

all streams. This is only applicable when the 4 concurrent streams from the device would

exceed the maximum MP capacity at full framerate. The frame rate balanced options

distributes frame rates equally through all streams, preventing the device from going over

the MP capacity.

Dewarping mode

Dewarping options are only available in Video 2 Dewarped view mode and in Video 3 E-PTZ.

Video 2 supports the modes described in the next section, depending on the camera mount

position. The camera mount position is configured in Positioning.

Video 3 only supports E-PTZ.

Click the Dewarping mode drop-down arrow to see the options. The options include:

– E-PTZ: One independent 16:9 dewarped view that can be treated as a PTZ camera

within the camera's field of view

– Quad: Four independent panoramic images are shown. The images can be adjusted

independently on the Live preview

– Panoramic: Generates a 180º view for wall mount scenarios (available when wall

mount is selected in the positioning menu)

– Double panoramic: Two independent panoramic images are shown. The images can be

adjusted independently on the Live preview

– Corridor: Two independent corridor images are shown. The images can be adjusted

independently on the Live preview

– Full panoramic: One panoramic image is shown

Notice!

The available dewarping modes depend on the type of installation: ceiling or wall.

Stream prioritization

Select the stream that should not drop any frame.

Coding standard

Select the coding standard you want to use for the stream.
