28 en | Configuration
FLEXIDOME panoramic 5100i | FLEXIDOME
panoramic 5100i IR
2024-11 | V03 | F.01U.385.628
User manual
Bosch Security Systems B.V.
Only through use of perspective information it is possible to distinguish objects such as
persons, bicycles, cars and trucks, and accurately compute their real size and speeds as
they move through 3D space.
However, to calculate perspective information accurately, the camera must be directed at a
single, flat horizontal plane. Multiple and inclined planes, hills, stairs can falsify perspective
information and produce incorrect object information such as size and speed.
Mounting position
The mounting position describes the perspective information that is also often called
calibration.
In general, the mounting position is determined by the parameters of the camera such as
height, roll angle, and tilt angle.
The height of the camera must always be entered manually. Whenever possible, roll angle
and tilt angle are provided by the camera itself.
Tilt angle [°]
Enter the tilt angle if the value is not determined by the camera.
The tilt angle describes the angle between the horizontal and the camera.
A tilt angle of 0° means that the camera is mounted in the ceiling.
A tilt angle of 90° means that the camera is mounted in a wall.
The flatter the tilt angle is set, the less accurate the estimate of object sizes and speeds will
be. The settings must be between 0° and 90°. Estimates are no longer possible when you
have reached 0°.
Roll angle [°]
Enter the roll angle if the value is not determined by the camera.
The roll angle describes the angle between the roll axis and the horizontal plane. The angle
can deviate from the horizontal by up to 45°.
Height [m]
Enter the height in meters of the position of the camera.
The height describes the vertical distance from the camera to the ground plane of the
captured image. Typically the elevation of the mounted camera above the ground.
Show sensor values...
Click to automatically see the camera parameters, for example, Tilt angle [°] and Roll angle
[°]. These calibration values are measured by the device sensors. Click OK to transfer them
to the Positioning settings page.
Lens rotation calibration
The IR zones are mapped correctly only when the lens is rotated in the default position. The
two arrows on the camera and lens must point at each other.
If the lens is manually rotated during installation, you can correct the IR zones by adjusting
this slider.
The values range from -180 to +180. Values below 0 are counterclockwise, while values
greater than 0 are clockwise.
Coordinate system
Select the coordinate system and enter the appropriate values in the additional input fields
that appear depending on the coordinate system selected.
The Coordinate system feature describes the position of the camera in a local Cartesian or
the global WGS 84 coordinate system. The camera and the objects tracked by the video
analytics are displayed on a map.
