FLEXIDOME panoramic 5100i | FLEXIDOME

panoramic 5100i IR

Configuration | en 21

Bosch Security Systems B.V.

User manual

2024-11 | V03 | F.01U.385.628

After setting the new language, click the Set button to apply changes. The GUI now displays

field names and options, as well as OSD messages, in the selected language.

Show VCA metadata

When video content analysis (VCA) is activated, additional information is displayed in the

live video stream. With the MOTION+ analysis type, for example, the sensor fields in which

motion is recorded are marked with yellow rectangles.

Using Intelligent Video Analytics, the outlines of detected objects are displayed in these

colors:

– Red: Objects that generate an alarm event under the current settings appear on the

camera image inside a red outline.

– Orange: An object that triggered an alarm event but does not generate another one

appears inside an orange outline (example: object has crossed a line). During forensic

search, an object that triggers an alarm event has an orange outline from the beginning.

– Yellow: Objects that are detected as moving but do not generate an alarm event under

the current settings appear inside a yellow outline.

Show VCA trajectories

For devices with Essential Video Analytics or Intelligent Video Analytics, the trajectories

(motion lines of objects) from the video content analysis are shown in the live video image if

a corresponding analysis type is activated. The trajectory is shown as a green line that

follows the object’s base point.

Show overlay icons

Select this check box to show overlay icons on the live video image.

Show VCA items

Select this checkbox to show VCA items on the live video image.

Shows alarm fields, lines and routes configured for the video analytics in the following

colors:

– Green: Fields, lines and routes used in a task are displayed in green. They can be edited

but not deleted.

– Red: Fields, lines and routes currently in alarm mode are displayed in red.

Show 'Dashboard'

Select this checkbox to enable the Dashboard in the application bar.

Secure cookies

Select this checkbox to secure the cookies sent through the camera.

Notice!

If cookies are secured, authentication forwarding to MPEG ActiveX and the Video Security

App is prohibited.

HTTP referrer check

Click this option to disable HTTP referrer checking. This option is enabled by default.

The HTTP referrer check works as a protection against a CSRF (Cross-site request forgery)

attack.

If a use case requires not sending the HTTP referrer, you can disable this option. In this

situation, you might require other mitigations against CSRF attacks.

Video player

Select the type of player to be used for live mode viewing.
