Functions and operation
EN
bora.com 29
If both cooking zones are already in use when the bridging function is
activated, the lower of the two power levels will be adopted for both
cooking zones.
If a timer is running when the bridging function is activated, this is
adopted. If 2 timers are running, the shorter one is used for the
bridging function.
Activating the bridging function
u
Touch command on both control knobs at the same time.
T
An acoustic signal can be heard and the bridging function is
activated.
T
The power level and both cooking zone indicators are shown on
both control knobs.
Fig.5.26
Activating the bridging function
Deactivating the bridging function
u
Set the power level to 0.
or
u
Touch command on both control knobs at the same time.
T
An acoustic signal can be heard and the bridging function is
deactivated.
T
The current power levels are retained.
T
Each cooking zone then goes back to being operated separately.
5.5.7
Pause function
With the pause function all cooking zones can be quickly and easily
deactivated temporarily. The cooking processes can be interrupted
for a maximum of 10 seconds. If the pause function is deactivated,
operation will resume with the original settings. Once 10 minutes
have lapsed, the cooking session is automatically ended.
The fan function, the bridging function and the (active) minute
minder cannot be interrupted. Active cooking zone timers are
stopped.
Activating the pause function
u
Double tap the cooktop extractor control knob.
T
The cooktop extractor display alternates between and the
current fan power level.
T
The cooktop control knob displays are dimmed and also show .
Fig.5.27
Activating the pause function
Deactivating the pause function
u
Double tap the cooktop extractor control knob
T
The cooktop control knob displays light up again.
T
Paused cooking zone timers resume their countdown.
Fig.5.28
Deactivating the pause function
5.5.8
Pan size recognition
On induction cooktops the cooking zone recognises the size of the
cookware automatically and only targets the energy at that area. It
also recognises cookware that is unsuitable or too small, or if there is
no cookware present. A cooking zone is not working if
/ are
alternated in the display. This happens if
T
it is switched on without cookware or with unsuitable cookware;
T
the base diameter of the cookware is too small;
T
the cookware is removed from a switched-on cooking zone.
If no pot is recognised 10 minutes after setting a power level, the
cooking zone will switch off automatically.
5.6
Cooktop function menu
Every appliance offers different additional functions. These can be
selected and activated via a function menu. Only the functions
available for each type of appliance are shown in the corresponding
function menu.
Menu item Designation
Heat retention function (3 levels)
Cooking zone timer
Automatic heat up function
Tab.5.5
Function menu on induction cooktops
Menu item Designation
Heat retention function (3 levels)
Cooking zone timer
Automatic heat up function
Tab.5.6
Gas cooktop function menu
