Functions and operation
EN
bora.com 27
Restricted functions when using the cooktops without a
cooktop extractor
If cooktops are installed and operated without a cooktop extractor,
only limited functions will be available. The following functions will not
be available:
T
System functions
T
Pause function
T
Short-time timer
T
Child lock
T
All settings/functions in the configuration menu
5.5.2
Special operating instructions for
the Tepan stainless steel grill
Initial operation:
u
Heat the griddle to 220°C for approx. 25 minutes before using it
for the first time (= power level 8 for both grilling zones).
T
Bothersome odours may be emitted during this process.
Operating instructions:
u
Clean the grill surface before using the appliance for the first time
(see"7Cleaning and maintenance").
u
Preheat the grilling zone for 5 minutes before it is used each time.
T
During heating or cooling the griddle may make some noise. This is
a normal occurrence.
T
A fan is built in to the Tepan stainless steel grill for cooling,
guaranteeing a long service life for the electronic components and
rapid cooling of the grill surface. Different measures have been
taken to keep noise to a minimum, but it cannot be completely
avoided.
T
During use, the griddle may show signs of curvature.
T
During grilling or heating on a high power level, the griddle may
adopt a light brown colour.
5.5.3
Special operating instructions for
the gas cooktop
When operating the cooktop for the first time or after a
prolonged period without use or when the liquid gas bottles
have been changed, it is possible that the burner may not
ignite. This may be due to air in the gas pipe or the electronic
gas regulator may need recalibrating. Follow the initial
operation instructions (see “Installation instructions”).
In the case of the gas cooktop, due to the use of enamelled
cast iron parts, slight colour variations and irregularities are
common. Furthermore, flash rust may appear at the support
points, which can be easily removed with a damp cloth. These
spots are normal and are not considered an impairment.
As a result of use, some of the components of the gas
cooktop can become discoloured. This discolouration is
normal and does not have a negative effect on the gas flame
or the functioning of the cooktop.
When using the gas burner, you may hear gas escaping from
it. The burner flame turns orange as a result of prolonged
operation and/or impurities on the burner and in the ambient
air (dust). These properties are normal and can occur
independently of one another.
In the event of smoke or fire while operating the gas cooktop,
turn off the gas supply and switch off the appliance at the wall
socket.
If you smell gas or have problems with the gas installation,
switch off the gas supply. Open the window and ensure good
ventilation.
Operating instructions:
The use of a gas cooktop results in the formation of heat and
moisture in the area where it is installed. Intensive use of the
appliance for a long time may require additional ventilation, e.g.
opening a window or more effective ventilation, e.g. operation of the
mechanical ventilation device at a higher power level.
u
Ensure sufficient ventilation.
u
Keep natural ventilation openings open.
u
Use a mechanical ventilation device if possible.
u
Do not put cookware with an uneven base on the pan support.
u
Never heat empty cookware.
u
Always place the cookware on the pan support provided. Cookware
must not be placed directly on the burner.
u
Do not use roasters, pans or stone grills that are so large that they
cover several burners. The resulting heat accumulation can
damage the cooktop.
u
Ensure that the burner parts and pan supports are positioned
correctly.
u
Do not switch the gas cooktop on until all burner parts are
correctly assembled.
u
Ensure that the burner flame does not protrude from under the
base of the cookware and rise up the outside of the pot.
u
Do not keep any highly flammable objects near the cooktop.
Only use cookware with a diameter that is within the given
dimensions. If the diameter is too large, the hot gases and
flames flowing outwards from under the base may damage
the worktop or any non-heat-resistant surfaces, e.g. walls
with panelling, as well as parts of the cooktop and the
cooktop extractor. Bora shall not be held liable for any such
damage.
Do not use the gas cooktop without cookware for extended
periods of time (>5 min) with the cooktop extractor switched
on. This results in very high temperatures and may damage
the gas cooktop and air-channelling components of the
cooktop extractor.
The tips of the flames should remain under the base of the
pot. Protruding flame tips emit heat into the air unnecessarily
and can damage pan handles and air-channelling components
(cooktop extractor) and increase the risk of burns.
Furthermore, the outer part of the gas flame is much hotter
than the core.
