Extended menu
EN
bora.com 39
6.3.1
Menu item P: PGU
Under menu item P (GPU) the minimum power of each burner and
gas type/pressure is regulated.
Setting Gas type Gas
pressure
(mbar)
Ø SR
burner/
normal
burner
Ø R burner/
high-power
burner
0 G20 screwdriver 104 125
G25 screwdriver 110 131
4 G30 29 69 85
G30/31 37 69 85
5 G30/31 50 62 78
10 G20 13 115 149
11 G25 25 104 131
G25.3 25 104 11
12 G20 25 100 119
Tab.6.1
Setting the gas type and gas pressure
Fig.6.5
Display menu item P: GPU
u
Select the correct setting. (Tap the corresponding slider segment
or setting via or )
6.3.2
Menu item S: GASt
You can select the characteristic curves for the gas burners here. The
characteristic curves regulate the minimum gas burner power values. The
minimum power levels are adjusted using the characteristic curves.
Depending on the installation situation and the influence of the cooktop
extractor, if necessary, the characteristic curve can be changed.
In the case of liquid gas (G30/31) only characteristic curves B
and C can be used.
Characteristic curve A:
A enables the fine tuning of the power values, which can only be
adjusted in the best-case scenario and only in the case of natural gas
(G20, G25, G25.3). The best-case scenario is when:
T
no cooktop extractor is in operation; or
T
the cooktop, when using the cooktop extractor in exhaust air
mode, is used with sufficient ventilation; or
T
the cooktop, when using the cooktop extractor in recirculation
mode is used with a sufficient return flow aperture and the cooktop
extractor does not have a negative influence on the gas flame.
Characteristic curve B:
B is the factory default characteristic curve with balanced adjustment
of the individual power levels.
Characteristic curve C:
C increases the lower power levels and should only be used in the
event of a negative influence from the cooktop extractor.
Selecting the characteristic curve
u
Select the appropriate characteristic curve (tap the corresponding
slider segment ).
Fig.6.6
Display menu item S: GASt
If the gas flame goes out, is excessively affected by the extractor
and/or the flame is not as it should be (e.g. soot production,
flame blowback, etc.), the characteristic curve must be increased,
as well as the ventilation in exhaust air mode, if necessary, or the
return flow aperture in recirculation mode.
6.3.3
Menu item T: GAS
This menu item provides a reset function. This reset function can be
used in the case of faults and errors and during initial operation if the
gas cooktop does not react (does not ignite). The set values for the
gas type, pressure and characteristic curve remain unchanged and
are not affected by the reset.
u
Perform a reset if necessary.
