59
CAUTION:
• It is recommended that the installation, water
connection and electrical connection be carried
out by a specialist.
Installation location
• Place the appliance so that all controls are easily
reached, and the appliance door can open without
being impeded.
• Take care of the solid and horizontal position of
the appliance.
• Power cord and water hoses may not kinked or
squashed.
• Avoid the installation:
- near heaters, next to a stove, direct sunlight or
any other heat sources;
- at locations with high humidity (e.g. outdoors),
as metal parts would be susceptible to corro-
sion under such circumstances;
- in rooms where the temperature could drop
below freezing. Do not expose the appliance
any weather.
- near volatile or flammable materials (e.g. gas,
fuel, alcohol, paint, etc.).
Water connection
CAUTION:
• The Installation of the water supply must conform
to the local laws and regulations.
• The appliance is not suitable for hot water supply.
• Use the new supplied hose set to connect the
appliance to the water supply. Do not reuse old or
used connection sets.
• If the water pipe is new or long time not used,
ensure before connecting to the water system,
that the water is clear and free from contamina-
tion.
NOTE, the connection to the water mains may only
be made in accordance with DIN EN 1717 of the
drinking water ordinance. A suitable safety device
against drinking water contamination through back-
flow must be installed.
Notes on inlet hose safety system (delivery scope
depending on model)
The safety system consists of a double-walled inlet
hose. It guarantees to cut off the water supply when
leakage of the inner hose. Switching off the water
supply leads to electronic contact.
If necessary, you can order an inlet hose safety sys-
tem from your dealer or in our online accessories
shop, https://www.profi-electro.de/produkte/
ersatzteile-zubehorshop.html. To order, use the ref-
erence number found under
“Technical data”
.
Set up water drain
Fig. page 3
• Attach the drainage hose to the appliance back.
The connector is provided with clamps and must
be fixed with a screwdriver.
• Secure the end of the hose securely in a sink or
bucket. Fix the drain hose with suction cups.
Set up water supply
Fig. page 3
You can fill the appliance with water in two ways:
Permanent connection via the tap
NOTE:
The water pressure must be between 0.04 MPa and
1.0 MPa. A pressure relief valve is required for higher
pressure.
• Connect the water inlet hose to a water valve with
a ¾" inch thread. Screw the connection on clock-
wise and ensure that it is secure.
• Connect the other end of the hose to the water
inlet connection on the back of the appliance,
making sure it is also securely attached.
