720P60, Speed can be selected from the following:

1/1, 1/2, 1/4, 1/8, 1/15, 1/30, 1/60, 1/90, 1/100, 1/125, 1/180, 1/250, 1/350, 1/500, 1/725, 1/1000, 1/1500, 1/2000, 1/3000,

1/4000, 1/6000, 1/10K.

IRIS: Select the iris the following: CLOSE, F14, F11, F9.6, F8.0, F6.8, F5.6, F4.8, F4.0, F3.4, F2.8, F2.4, F2.0, F1.6

EX-COMP: (Exposure Compensation)

When MODE is set to one of FULL AUTO, SHUTTER PRI or IRIS PRI, set this item to ON to enable exposure

compensation. When you set EX-COMP to ON, LEVEL appear and you can select the exposure compensation

level from the following:

–10.5, –9, –7.5, –6, –4.5, –3, –1.5, 0, +1.5, +3, +4.5, +6, +7.5, +9, +10.5

If you set the level to 0, exposure compensation will be disabled. Level +10.5 is the brightest and –10.5 is the

darkest compensation value.

When EX-COMP is set to OFF, exposure compensation does not function.

WHITE BALANCE Menu

The WHITE BALANCE menu is used to select the white balance mode.

MODE (white balance mode)

Select the white balance mode from the following:

AUTO: This mode computes the white balance

value output using color information from the entire

screen. It outputs the proper value using the color

temperature radiating from a black subject based on

a range of values from 2500K to 7500K. This mode

is the initial setting.

INDOOR: 3200K Base Mode

OUTDOOR: 5800K Base Mode

OPW (One Push White Balance): The One Push White Balance

mode is a fixed white balance mode that may be automatically

readjusted only at the request of the user (One Push Trigger),

assuming that a white subject, in correct lighting conditions, and

occupying more than 1/2 of the image, is submitted to the camera.

One Push White Balance data is lost when the power is turned off. If

the power is turned off, reset One Push White Balance.

NOTE: When you select the OPW (One Push White

Balance)

Perform the following operations:

1. Place an image of white subject (For example: A piece of

white paper) in the center of the screen.

2. Press the HOME button of the infrared remote controller.

The one-push white balance adjustment is activated.

ATW (Auto Tracking White Balance): Auto Tracking White

balance (2000K to 10000K), allows the camera to adjust the tone

according to the temperature of the light source illuminating the

subject

USER: This is a mode that enables you to manually set the control of

R and B gain up to 256 steps.

NOTE: When you select USER, R. GAIN (red gain) and B. GAIN

(blue gain) appear. You can select each item in the range from 0 to

255.

EXPOSURE

>WHITE BALANCE

>PICTURE

PAN TILT ZOOM

>SYSTEM

OSD

WB MODE AUTO

WHITE BALANCE MENU

WB MODE INDOOR

WHITE BALANCE MENU

WB MODE OUTDOOR

WHITE BALANCE MENU

WB MODE OPW

WHITE BALANCE MENU

WB MODE USER

R GAIN 106

B GAIN 217

WHITE BALANCE MENU

WB MODE ATW

WHITE BALANCE MENU
