Control Button

You can select the item by pressing “↑, ↓, ←, →” and HOME button.

You can select a menu item by

“↑, ↓”

button on the infrared remote

controller

. The selected item is shown by the

cursor (Color change).

You can change the value of the item by pressing “←, →” button.

You can move to the next layer by

pressing the HOME button.

You can return to the normal display by

pressing the DATA SCREEN button.

When you are operating the menu using the infrared remote controller, you cannot set IR- RECEIVE in the SYSTEM

menu to OFF. To set IR- RECEIVE to OFF, use the appropriate VISCA command.

EXPOSURE Menu

The EXPOSURE menu is used to set the items related to exposure.

MODE (Exposure Mode)

FULL AUTO: The exposure is adjusted

automatically using the values set for EX-COMP

(Exposure Compensation).

MANUAL: Adjust the GAIN, electronic shutter

speed (SPEED), iris (IRIS) manually.

IRIS PRI: Iris Priority mode. The exposure is

adjusted automatically using the values manually set

for iris (IRIS) and EX-COMP.

SHUTTER PRI: Shutter Priority mode. The

exposure is adjusted automatically using the values manually set for electronic shutter speed (SPEED) and EX-

COMP.

Bright: Bright Priority mode. The exposure is adjusted automatically using the values manually set for electronic

brightness level.

When you select one from various exposure modes, some of the following setting items that are required for the selected

mode will appear.

GAIN: Select the gain from the following:

0dB, 3.6 dB, 7.1 dB, 10.7 dB, 14.3 dB, 17.8 dB, 21.4 dB, 25 dB, 28.6 dB, 32.1 dB, 35.7 dB, 39.3 dB, 42.8 dB, 46.4 dB,

50 dB

SPEED: Select the electronic shutter speed from the following:

When video format is set to 720P25, 1080P50, 1080i50, 1080P25, 720P50, Speed can be selected from the following:

1/1, 1/2, 1/3, 1/6, 1/12, 1/25, 1/50, 1/75, 1/100, 1/120, 1/150, 1/215, 1/300, 1/425, 1/600, 1/1000, 1/1250, 1/1750, 1/2500,

1/3500, 1/6000, 1/10K.

When video format is set to 720P30, 1080i59.94, 1080P29.97, 720P59.94, 1080P59.94, 1080I60, 1080P30, 1080P60,

Note

MODE MANUAL

GAIN 12dB

SPEED 1/60

IRIS F1.6

EXPOSURE MENU: MANUAL

>EXPOSURE

>WHITE BALANCE

>PICTURE

PAN TILT ZOOM

>SYSTEM

OSD

MODE FULL AUTO

>EX COMP OFF

EXPOSURE MENU: FULL AUTO

MODE IRIS PRI

IRIS F1.6

EX-COMP OFF

EXPOSURE MENU: IRIS PRI

MODE SHUTTER PRI

SPEED 1/60

EX-COMP OFF

EXPOSURE MENU: SHUTTER PRI

MODE BRIGHT

LEVEL 7

EXPOSURE MENU: IRIS PRI
