15
SD Card (Not activated, for future supported by software upgrade)
Micro SD card can be inserted to the camera for local recording.
• Ensure that the Micro SD card’s pins are faced downward (logo faced up)
• Slide the card into the slot, and click into place
• To remove the card, click inward, and it will pop outward and may be removed
• See Manual part 2 for more information regarding SD recording
Currently, the following Micro SD cards are supported:
Camera Initial setting status Information
Information of the camera initial setting status will display for 5
seconds.
1. Camera PELCO ID for RS-485 control
2. Camera VISCA ID for RS-422/RS-232 control
3. Camera ID for IR Remote Controller
4. IR remote control signal receive current setting
5. Baud Rate current setting
6. Control COM Port current setting
7. Video format current setting
8. HDMI current setting
9. Model number
10. MCU firmware version
11. FPGA firmware version
PELCO ID 1
VISCA ID 1
IR ID 1
IR-RECEIVE ON
BAUD RATE 9600
COMM TYPE 422
FORMAT 2160P29.97
HDMI OUT YUV
MODEL TYPE ----
MCU FW: V0K010B35010AA010
FPGA FW: V027 4K
Camera Status Info Display
