Product Assembly - Preassembly Tips - GT

PREASSEMBLY TIP #1 – “Stage Right”.

During the assembly process we will be stating Right, Left, Front, Back, Top, or Bottom. These

all are in the perspective of the user in the machine facing outward with feet on the ground.

See below images as examples.

PREASSEMBLY TIP #2 – Unpackaging & organizing.

PREASSEMBLY TIP #3 – Keep hardware loose until asked to tighten.

During the assembly, hardware needs to be finger tight until the STEPS of “Torque Time”. This will

ensure sub-frame and other parts will easily fit together and not strip out bolt threads during assembly.

16

The best practice in assembly is to take all the

parts out of the boxes & bags and line up in order

of assembly. This enables a mindset of what you

will be assembling, their physical sizes and what

challenges you might face BEFORE you begin.

Right Side

Back

Front

Left Side

Top
