Product Assembly, GT-LP (Leg Press), STEP 4 - OVERVIEW
20
STEP 2c: Install Foot Plate to Bottom Frame
View Keys
Red dashed lines (large): Structural parts assembled direction.
Red dashed lines (med): Sub-parts assembled direction.
Blue dashed lines (small): Hardware assembled direction.
Orange (med): Cables are normally black, but easier to see in color.
Pulley P39
4-1/2”
228
Pulleys
P35 - P38 & P40
3-1/2”
227
Pulleys are numbered
w/ GREEN circles for
installation routing.
Part # Assembly Parts List QTY
GT-X-LP-217 Cable, Leg Press, 4,850mm (191") 1
Pulleys are numbered
w/ GREEN circles for
installation routing.
4,850mm ( 191” )
NOTE: Actual color of Leg Press
Cable #217 is black. Shown in the
assembly STEPS in ORANGE for
easy viewing.
