MX44KVM USER MANUAL
Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk
05
This following pages outlines the operation of the Matrix Web-GUI. Connect the TCP/IP RJ45 socket to the local
network in order to access the products Web-GUI, or connect a PC directly to the TCP/IP port for initial configuration.
By default the Matrix is set to DHCP, however if a DHCP server (eg: network router) is not installed the matrix IP address
will revert to the below details:
Default IP Address: 192.168.0.200 Default Username: blustream Default Password: 1234
The Web-GUI supports multiple users along with multiple user permissions as follows:
Guest Account - This account does not require a user to login. The Guest account can only change sources for each
zone. Guest access can be changed by the Admin, limiting inputs or outputs as necessary.
User Accounts - 7x User accounts can be utilised, each with individual login details. User accounts can be assigned
permissions to specific areas and functions. A User must log in to make use of these functions.
Admin Account - This account allows full access to all functions of the Matrix, as well as assigning users with individual
permissions.
Web-GUI Control
The Blustream range of matrix products include Matrix control via IR.
IMPORTANT: Blustream Infrared products are all 5V and NOT compatible with alternative manufacturers
Infrared solutions. When using third party 12V IR control solutions please use the Blustream IRCAB cable for IR
conversion.
IR Receiver - IRR
Blustream 5V IR receiver to receive
an IR signal for control of the matrix.
IR Control Cable - IRCAB (supplied)
Blustream IR Control cable 3.5mm Mono to
3.5mm Stereo for linking third party control
solutions to Blustream products.
Compatible with 12V IR 3 party products.
Please Note: cable is directional as
indicated.
IR Receiver - Stereo 3.5mm
Infrared (IR) Control
Signal
5V
Ground
