CUSTOM PRO MATRIX USER MANUAL

Custom Pro Matrix Output Boards

PRO-OUT4H-V2 - 4-Way HDMI 2.0 Output Board (4K 60Hz 4:4:4 - 18Gbps)

• 4 x HDMI 2.0, female

PRO-OUT2H-V2 - 2-Way HDMI 2.0 Output Board (4K 60Hz 4:4:4 - 18Gbps)

• 2 x HDMI 2.0, female

Output

OUT2H-V2

1 HDMI Outputs

Output

OUT4H-V2

1 HDMI Outputs

HDMI In

PRO-OUT4HTCS - 4-Way HDBaseT™ CSC / HDMI 2.0 Output Board (4K 60Hz 4:4:4 - 18Gbps to 70m)

• 4 x HDBaseT™ CSC, RJ45

• 4 x simultaneous HDMI 2.0, female

• Supports 70m at 4K 60Hz 4:4:4, or 100m at 1080p when used with the HEX100CS-RX

• HEX70CS-RX can be used where CAT cable distance is less than 40m at 4K 60Hz 4:4:4, or 70m at 1080p

• Supports PoC (Power over Cable) to compatible Blustream HDBaseT™ receivers

OUT4HTCS

1 HDBaseT™ PoC Outputs (RJ45)

2 HDMI Outputs

HDMI In

1 2
