www.blustream.co.uk | www.blustream.com.au

CUSTOM PRO MATRIX USER MANUAL

OUT4TCS

Custom Pro Matrix Output Boards

PRO-OUT4TCS - 4-Way HDBaseT™ CSC Output Board (4K 60Hz 4:4:4 - 18Gbps to 70m)

• 4 x HDBaseT™ CSC, RJ45

• Supports 70m at 4K 60Hz 4:4:4, or 100m at 1080p when used with the HEX100CS-RX

• HEX70CS-RX can be used where CAT cable distance is less than 40m at 4K 60Hz 4:4:4, or 70m at 1080p

• Supports PoC (Power over Cable) to compatible Blustream HDBaseT™ receivers

PRO-OUT2TCS - 2-Way HDBaseT™ CSC Output Board (4K 60Hz 4:4:4 - 18Gbps to 70m)

• 2 x HDBaseT™ CSC, RJ45

• Supports 70m at 4K 60Hz 4:4:4, or 100m at 1080p when used with the HEX100CS-RX

• HEX70CS-RX can be used where CAT cable distance is less than 40m at 4K 60Hz 4:4:4, or 70m at 1080p

• Supports PoC (Power over Cable) to compatible Blustream HDBaseT™ receivers

1 HDBaseT™ PoC Outputs (RJ45)

PRO-OUT4TLS-V2 - 4-Way HDBaseT™ CSC / HDMI2.0 Output Board (4K 60Hz 4:4:4 - 18Gbps to 40m)

• 4 x HDBaseT™ CSC, RJ45

• 4 x Simultaneous HDMI 2.0, female

• Supports 40m at 4K 60Hz 4:4:4, or 70m at 1080p when used with the HEX70CS-RX

• Supports PoC (Power over Cable) to compatible Blustream HDBaseT™ receivers

OUT4TLS-V2

1 HDBaseT™ PoC Outputs (RJ45)

2 HDMI Outputs

HDMI In

OUT2TCS

OUT4TLS-V2

1 2
