HMX44-18G-KIT QUICK REFERENCE GUIDE

www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk

Package ContentsSpecifications

• 1 x HMX44-18G

• 4 x RX18G

• 1 x Rack mounting kit

• 1 x Remote control

• 4 x IR emitters

• 5 x IR receivers

• 1 x Serial Cable - DB9 to 3-pin phoenix

connector

• 1 x IR Control Cable - 3.5mm-3.5mm Cable

• IEC Power Cable(s)

• 1 x Quick Reference Guide

NOTE: Specifications are subject to change without notice.

Weights and dimensions are approximate.

• Video Input Connectors: 4 x HDMI Type A, 19-pin, female

• Video Output Connectors: 1 x HDMI Type A, 19-pin, female,

4 x HDBaseT™ RJ45 connectors

• Audio Input Connectors: 1 x Analogue audio L/R (3.5mm stereo

Jack), 1 x Optical (S/PDIF)

• Audio Output Connectors: 4 x Analogue audio L/R (3.5mm

stereo Jack), 4 x Optical (S/PDIF)

• RS-232 Serial Port: 5 x 3-pin phoenix connector

• TCP/IP Control Port: 1 x RJ45, female

• Ethernet Passthrough Port: 1 x RJ45, female

• IR Input Ports: 6 x 3.5mm stereo jack

• IR Output Ports: 5 x 3.5mm mono jack

• Product Upgrade Port: 1 x Micro USB, female

• Rack Mountable: 1U rack height, rack ears included

• Casing Dimensions (W x H x D): 436mm x 360mm x 44mm

(without feet)

• Shipping Weight: 8.7kg

• Operating Temperature: 23°F to 131°F (-5°C to +55°C)

• Storage Temperature: -13°F to 158°F (-25°C to +70°C)

• Power Supply: Internal 100-240V AC

• HDBaseT Power Output: 24V DC 0.75A per port

FCC NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAUTION - changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to

operate the equipment.

CANADA, INDUSTRY CANADA (IC) NOTICES

This Class B digital apparatus complies with Canadian ICES-003.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any

interference, including interference that may cause undesired operation of the device.

CORRECT DISPOSAL OF THIS PRODUCT

This marking indicates that this product should not be disposed with other household wastes. To prevent possible harm to the

environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material

resources. To return your used device, please use the return and collection systems or contact the retailer where the product was

purchased. They can take this product for environmentally safe recycling.

Certifications
