HEX70ARC-KIT QUICK REFERENCE GUIDE

Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk

Package Contents

Specifications

HEX70ARC-KIT

• 1 x HEX70ARC-TX and 1 x HEX70ARC-RX

• 1 x 24V/1.25A DC Power Supply

• 1 x IR Emitter

• 1 x IR Receiver

• 2 x Mounting Bracket Sets

• 1 x Quick Reference Guide

NOTE: Specifications are subject to change without notice. Weights and

dimensions are approximate.

HEX70ARC-TX

• Video Input Connectors: 1 x HDMI Type A, female

• Video Output Connectors: 1 x HDBaseT™ RJ45

connector, 1 x HDMI Type A, female

• Audio Output Ports: 1 x Optical (S/PDIF), 1 x 3.5mm

L/R analogue audio

• IR Input Port: 1 x 3.5mm stereo jack

• IR Output Port: 1 x 3.5mm mono jack

• Product Upgrade: 1 x Micro-USB, female

• Casing Dimensions (W x D x H): 135 x 84 x 21mm

HEX70ARC-KIT

• Power Supply: 1 x 24V/1.25A DC, 4-pin DIN connector

• Box Dimensions (W x D x H): 248 x 151 x 103mm

• Shipping Weight: 1kg

• Operating Temperature: 32°F to 104°F (-5°C to +55°C)

• Storage Temperature: -4°F to 140°F (-25°C to +70°C)

HEX70ARC-RX

• Video Input Connectors: 1 x HDBaseT™ RJ45 connector

• Video Output Connectors: 1 x HDMI Type A, female

• IR Input Port: 1 x 3.5mm stereo jack

• IR Output Port: 1 x 3.5mm mono jack

• Product Upgrade: 1 x Micro-USB, female

• Casing Dimensions (W x D x H): 135 x 84 x 21mm

FCC NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC

Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAUTION - changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to

operate the equipment.

CANADA, INDUSTRY CANADA (IC) NOTICES

This Class B digital apparatus complies with Canadian ICES-003.

Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any

interference, including interference that may cause undesired operation of the device.

CORRECT DISPOSAL OF THIS PRODUCT

This marking indicates that this product should not be disposed with other household wastes. To prevent possible harm to the

environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material

resources. To return your used device, please use the return and collection systems or contact the retailer where the product was

purchased. They can take this product for environmentally safe recycling.

Certifications
