01
DA11AEN-V2 QUICK REFERENCE GUIDE
Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk
Our DA11AEN-V2 has been designed to encode unbalanced or balanced 2ch
analogue audio to Dante® digital signals. The DA11AEN-V2 allows any non-Dante®
audio source such as mixing consoles, amplifiers, computers and Blustream Matrix
products or distribution products to be connected as a source within a Dante®
network. The DA11AEN-V2 is a plug & play device that is powered using either
PoE (Power Over Ethernet) from any PoE network switch or via a local 12V power
supply input. The DA11AEN-V2 also supports AES67 RTP audio transport. The in-
built web interface module can be used for configuration and control of the device.
Introduction
• Encodes unbalanced or balanced 2ch analogue audio to Dante® digital signals
• Supports 44.1, 48, 88.2 & 96 KHz sample rates @ 16/24/32 Bit
• Configurable Dante® device latency (supports 2-10ms configurable using Dante® Controller)
• Supports AES67 RTP audio transport
• Web interface module for control and configuration of the device
• Features Class 0 802.3af PoE for powering of product from any PoE switch
• Local 12V power supply input for when network switch does not support PoE*
* PS121PH power supply sold separately
DA11AEN-V2
Quick Reference Guide
FEATURES:
Connections:
1 Dante® Audio Output - RJ45 socket connects Dante® network.
2 DC Input - Connect to +12VDC power supply (not supplied) if
device is not powered via a PoE switch
3 Audio Input - Phoenix Connector accepts balanced or
unbalanced 2 channel audio input.
Front Panel
1
Rear Panel
3
Wiring Configuration
Balanced - XLR
Unbalanced - RCA
+
-
-
+
2
