BLUARC USER MANUAL
Contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk
11
Input Selection:
The desired audio input can be selected by pressing the corresponding button.
Output Volume:
The volume for the analogue or Bluetooth output devices can
be adjusted by using the corresponding slider for the desired
channel. Fine-tuning of the volume can be achieved by using the
decrement button 1 or the increment button 3, or by manually
inputting the value 2. The output can be muted by pressing the
mute button 4.
The front panel volume buttons will control the highlighted
output. This can be changed in the System page of the web-GUI.
1 2 3 4
Bluetooth Settings:
The BLUARC can act as a Bluetooth receiver or transmitter:
– A maximum number of 2 Bluetooth devices can be connected at the same time in TX mode. However, the BLUARC can store
up to 8 devices ready to be paired
– Only a single Bluetooth device can be connected in RX mode. The user must disconnect the current Bluetooth device in
order to connect a new device
Please note: the BLUARC cannot receive and transmit audio at the same time.
Bluetooth Mode
– Auto
– When in Auto mode, the BLUARC will automatically determine which mode to operate in (i.e., when Bluetooth is
selected as the input source, the BLUARC will switch to RX mode)
– TX
– The BLUARC will only operate in TX mode, regardless of the input selected
– RX
– The BLUARC will only operate in RX mode
Please note: the Bluetooth module needs to be restarted aer switching between TX and RX modes, which will take
approximately 3-4 seconds.
Bluetooth Name
– Sets the Bluetooth broadcast name for the BLUARC
– Limit of 30 characters, and some special characters may not be supported
Bluetooth Receiver:
Bluetooth Pairing
– OFF
– Bluetooth broadcasting is disabled and no Bluetooth connection is possible
– ON
– The Bluetooth signal is constantly broadcasting and Bluetooth devices can connect at any time. Please note: Once
a Bluetooth source is connected, the BLUARC will stop broadcasting. The Bluetooth broadcasting will automatically
resume once the Bluetooth source is disconnected
– Manual
– Bluetooth will only broadcast once the front panel Pair button has been pressed or when triggered by pressing the Pair
button on the web-GUI or via API
– Timeout (available in manual pairing mode)
– Set the Bluetooth broadcast timeout for manual pairing. Interval can be set between 1-999 seconds. The remaining
time will be displayed in the countdown timer. Once the timer reaches zero, the BLUARC will exit pairing mode
