18
Blaze 20-Inch 4.3 Cu. Ft. Compact Refrigerator and 4.5 Cu. Ft. Compact Beverage Cooler
BlazeGrills.com
Tools Required: Phillips head screwdriver.
Step 1: Remove Top Right Hinge: Using a helper
locate the top right hinge on the refrigerator. Remove
the 3 screws securing the hinge plate using a screw-
driver. Set the hinge plate and screws aside. It may be
necessary to open or close the door partiality to allow
for access
Step 2: Remove the Door: Carefully lift the door
straight up off the bottom hinge pin. Set the door
aside on a soft, flat surface to prevent scratches.
Step 3: Transfer Bottom Hinge Plate: Locate the
bottom hinge plate at the base of the door. Remove
the 2 screws holding the hinge plate. Move the hinge
plate to the opposite side of the door. With the BLZ-
GDBEV20-4.5 this will require flipping the door.
Secure it with the same 2 screws. Screw this through
the metal sticker on the bottom of the fridge door if
you have the BLZ-GDBEV20-4.5.
Step 4: Remove and Reposition Handle: If you have
the BLZ-SSRF20-4.3. Reattach the handle to the
opposite side of the door using the same screws.
1
2
How to Reverse the Door Swing
Step 5: Reattach the Door: Using a helper, care-
fully place the door onto the left bottom hinge pin.
Ensure the door is properly aligned and level. For BLZ-
SSRF-4.3, you need to use the left bottom hinge axis
plate in the accessory bag. For the BLZ-GDBEV20-4.5,
before attaching the door back to the hinges, you must
flip the door‘s ajar sensor to the bottom of the door
and the door stopper to the left bottom of the door.
Step 6: Attach Top Hinge on New Side: Take the top
hinge left plate that shipped with the fridge. Position it
on the top left corner of the refrigerator. Secure it with
the three screws you removed earlier.
Final Check: Open and close the door to ensure it
swings smoothly. Check that the door seal is making
proper contact all around, and the door ajar sensor is
being pushed in before tightening all the screws.
1
2
3
1
2
3
4
1
2
3
Step 4
Step 5
Step 6
Steps 2 & 3
