Peak

Camera focus can easily be checked by pressing the ‘peak’ button to enable focus peaking.

This displays a bright green edge around the sharpest points in your image. There are two

levels of peaking strengths which you can cycle through with subsequent pressing of the peak

button. When the green edges are at their strongest, you can be sure your camera is in focus.

3D LUT 1 and 3D LUT 2

The LUT buttons let you view your image using custom 3D LUTs generated in DaVinci Resolve,

or industry standard .cube LUTs. Press a LUT button once to enable the LUT. Press again to

disable the LUT. Refer to the ‘loading 3D LUTs using Blackmagic SmartView Setup’ section for

more information on using 3D LUTs with SmartView 4K G3.

H Mark and V Mark

You can view and edit frame markers using the ‘H mark’ and ‘V mark’ buttons. Frame markers

help you compose shots or keep important information or graphics within the safe area of the

screen. Different televisions display slightly more or less of the edges of a video signal, so it’s

handy to view a safe area. A safe area is the section of the screen that will always be visible no

matter what television or monitor is being used to view it.

To view horizontal and vertical frame markers, press the H mark and V mark buttons respectively.

To edit the markers, press each respective button again to highlight each guide. This allows you

to edit the markers’ positions using the up and down arrow buttons. Subsequent presses of each

button will confirm your new positions. Another press turns the markers off.

INPUT DISP

H/V

DELAY

BLUE

ONLY

3D

LUT 1

3D

LUT 2

H

MARK

V

MARK

ZOOM PEAK

USE ONLY 250V FUSES

INPUT DISP

H/V

DELAY

BLUE

ON LY

3D

LUT 1

3D

LUT 2

H

MARK

V

MARK

ZOOM PEAK

USE ONLY 250V FUSES

Up and Down Arrow Buttons

Use the up and down arrow buttons when editing a setting, for example adjusting the display

brightness or editing frame marker positions.

Power

Press the power button once to turn your SmartView 4K G3 on. Press again to turn off.

12Using SmartView 4K G3
