9
English
Installing/Removing Sanding Sheets
(Fig.F)
Optional Accessory
A diamond shaped platen uses a hook and loop adhesion
system to attach the sanding sheets. The platen allows you to
use it on large flat surfaces and tight spots orcorners.
1. Attach the sanding platen accesory as described under
Installing/RemovingAccessories.
2. Align the edges on the sanding sheet with the edge
of the sanding platen and press the sanding sheet
onto the platen.
3. Firmly press the base with the sanding sheet
attached against a flat surface and briefly switch the
Attaching Accessories Using the
Universal Adapter (Fig. E)
CAUTION: To avoid injury, do not use any accessory
for an application where the adaptor may fail to hold
theaccessory.
CAUTION: Read and follow all manufacturers' safety
warnings for any accessories used with thistool.
CAUTION: To avoid injury, ensure adaptor and
accessory are securelytightened.
Non‑BLACK+DECKER accessories can be attached using the
universaladaptor.
1. Place the washer
12
on thetool.
2. Place accessory
9
on towasher.
3. Tighten and secure adaptor nut
13
using hex
wrench
14
.
To purchase any of the following accessories, please contact
your local service center.
Part Part number
Outer flange 90583886
Screw 90583887
Ring 90583888
Flange N440293
Installing/Removing Accessories (Fig.C, D)
The tool features an exclusive tool‑free system for faster
accessory changes and adjustments without the need for
wrenches or hex keys like other oscillating toolsystems.
1. Grasp the tool and squeeze the tool‑free accessory
clamp lever
4
.
2. Clean any residual debris from the tool shaft
8
and
the tool‑free accessory clamp holder.
3. Slide the accessory
9
between the shaft and the
accessory holder
10
making sure the accessory
engages all of the pins
11
on the holder and is flush
with the shaft.
4. Release the tool‑free accessory clamp lever.
5. Some accessories, such as scrapers and blades can
be mounted at an angle if required as shown in
Fig.D.
WARNING: Risk of lacerations or burns. Do not touch
the sharp edges of accessories at any time. Do not
touch workpiece or blade immediately after operating
the tool. They can become very hot. Handle carefully.
Always allow accessories and work piece to cool
beforehandling.
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can causeinjury.
switches to the pack charging mode. This feature ensures
maximum battery packlife.
A cold battery pack may charge at a slower rate than a warm
batterypack.
The hot/cold pack delay will be indicated by the red light
continuously flashing a short ON followed by a longer ON
(see charger for blink pattern). Once the battery pack has
reached an appropriate temperature, the charger will resume
the chargingprocedure.
Electronic Protection System
Li‑Ion tools are designed with an Electronic Protection
System that will protect the battery pack against overloading,
overheating or deep discharge. The tool will automatically
turn off and the battery pack will need to berecharged.
Important Charging Notes
1. The charger and battery pack may become warm to the
touch while charging. This is a normal condition, and
does not indicate a problem. To facilitate the cooling of
the battery pack after use, avoid placing the charger or
battery pack in a warm environment such as in a metal
shed or an uninsulatedtrailer.
2. If the battery pack does not charge properly:
a. Check operation of receptacle by plugging in a lamp
or other appliance;
b. Check to see if receptacle is connected to a light
switch which turns power off when you turn out
the lights;
c. If charging problems persist, take the tool, battery
pack and charger to your local servicecenter.
3. You may charge a partially used pack whenever you
desire with no adverse effect on the batterypack.
Charger Cleaning Instructions
WARNING: Shock hazard. Disconnect the charger from
the AC outlet before cleaning. Dirt and grease may be
removed from the exterior of the charger using a cloth
or soft non‑metallic brush. Do not use water or any
cleaningsolutions.
SAVE THESE INSTRUCTIONS FOR
FUTURE USE
